Naval Systems

Arleigh Burke-class guided-missile destroyer

The Arleigh Burke class is the U.S. Navy's long-running DDG 51 guided-missile destroyer family, built around the Aegis Weapon System, Mk 41 vertical launch cells, gas-turbine propulsion, and multi-mission air, surface, subsurface, ballistic-missile-defense, and land-attack roles. The class entered service with USS Arleigh Burke in 1991, spans Flight I through Flight III hulls, and continues in production with the Flight III configuration centered on AN/SPY-6(V)1 radar and Aegis Baseline 10.

Role in Conflicts

U.S. Navy Arleigh Burke-class destroyers, including USS Winston S. Churchill, USS Frank E. Petersen Jr., USS Thomas Hudner, USS Delbert D. Black, and USS Spruance, fired Tomahawk Land Attack Missiles in support of Operation Epic Fury against Iran in 2026.

Profile / Specs

Profile

Origin
United States
Type
Guided-missile destroyer
Service note
Commissioned from 1991; still in U.S. Navy production and service
Designer
Gibbs & Cox
Designed
1980s
Produced
1988-present

Specifications

Length
505 ft for Flight I/II ships; 509.5 ft for Flight IIA/III ships
Beam
59 ft
Displacement
About 8,230-9,700 long tons
Propulsion
Four General Electric LM2500-30 gas turbines, two shafts, 100,000 total shaft horsepower
Speed
In excess of 30 knots
Crew
Flight IIA: 329; Flight III: 359
Combat system
Aegis Weapon System with Mk 41 Vertical Launching System; Flight III integrates AN/SPY-6(V)1 and Aegis Baseline 10
Armament
Mk 41 Vertical Launching System for Standard Missiles, Tomahawk, ASROC, ESSM, plus 5-inch gun, torpedoes, and close-in weapons
Aviation
Flight IIA and Flight III ships support two LAMPS Mk III MH-60R helicopters
Variants

The U.S. Navy groups DDG 51 hulls by flight: original Flight I ships, Flight II ships, helicopter-capable Flight IIA ships, and Flight III ships centered on the AN/SPY-6(V)1 Air and Missile Defense Radar.

VariantConfigurationDesignation notes
Flight IOriginal DDG 51 design

The Navy identifies DDGs 51-71 as Flight I ships.

Sources: Destroyers (DDG 51)

Flight IISecond production flight

The Navy identifies DDGs 72-78 as Flight II ships.

Sources: Destroyers (DDG 51)

Flight IIAExpanded aviation-capable flight

The Navy identifies DDGs 79-124 and DDG 127 as Flight IIA ships; its fact file lists two LAMPS Mk III MH-60R helicopters for Flight IIA and III ships.

Sources: Destroyers (DDG 51)

Flight IIIAN/SPY-6 and Aegis Baseline 10 flight

The Flight III baseline begins with DDGs 125-126 and continues with DDG 128 and follow; the Navy describes the upgrade as centered on AN/SPY-6(V)1 for integrated air and missile defense.

Sources: Destroyers (DDG 51), USS Jack H Lucas Commissions in the Sun State at Port Tampa Bay

Carried Munitions

The DDG 51 fact file lists the class's carried weapons in its armament summary, including the Standard Missile family, ESSM, Vertical Launch ASROC, Tomahawk, and six MK-46 torpedoes from two triple tube mounts.

Carried itemItem typeCarriage evidence
Evolved Sea Sparrow Missile, Ship self-defense missile, MunitionsEvolved Sea Sparrow MissileShip self-defense missile

The DDG 51 fact file lists Evolved Sea Sparrow Missile in the Arleigh Burke-class armament alongside the class's Mk 41 vertical launch battery.

Sources: Destroyers (DDG 51)

Standard Missile-2 (SM-2), Shipboard surface-to-air missile family, MunitionsStandard Missile-2 (SM-2)Surface-to-air missile

The DDG 51 fact file lists the Standard Missile family in the Arleigh Burke-class armament, placing SM-2-family fleet air-defense missiles within the class's vertical-launch weapon set.

Sources: Destroyers (DDG 51)

Standard Missile-3 (SM-3), Ship- and ground-launched exo-atmospheric ballistic missile interceptor, Air DefenseStandard Missile-3 (SM-3)Ballistic missile defense interceptor

The DDG 51 fact file ties Aegis Baseline 9 ships to ballistic missile defense and lists the Standard Missile family in the class armament, supporting SM-3 as part of the Aegis BMD missile relationship for capable ships.

Sources: Destroyers (DDG 51)

Standard Missile-6 (SM-6), Ship-launched multi-mission interceptor missile, Air DefenseStandard Missile-6 (SM-6)Multi-mission fleet air-defense missile

The DDG 51 fact file lists the Standard Missile family in the Arleigh Burke-class armament and describes the class's air-warfare and missile-defense roles, supporting SM-6 as a Standard-family missile relationship for modern Aegis ships.

Sources: Destroyers (DDG 51)

MK-46 torpedo, Lightweight anti-submarine torpedo, MunitionsMK-46 torpedoLightweight anti-submarine torpedo

The DDG 51 fact file lists six MK-46 torpedoes from two triple tube mounts in the class armament summary.

Sources: Destroyers (DDG 51)

RUM-139 VL-ASROC, Vertical-launch anti-submarine missile, MunitionsRUM-139 VL-ASROCAnti-submarine missile

The DDG 51 fact file lists ASROC in the Arleigh Burke-class armament summary, and the VLA fact file identifies the missile as a surface-ship launched anti-submarine weapon carried by Aegis-equipped destroyers with Mk 41 VLS.

Sources: Destroyers (DDG 51), Vertical Launch Anti-Submarine Rocket ASROC (VLA) Missile

Launched Munitions
Launched itemItem typeLaunch evidence
BGM-109 Tomahawk Land Attack Missile, Ship- and submarine-launched land-attack cruise missile, MunitionsBGM-109 Tomahawk Land Attack MissileLong-range land-attack cruise missile

Navy sources state the DDG 51 class houses Tomahawk in its Mk 41 VLS, and the Tomahawk fact file says the missile is launched from U.S. Navy surface ships.

Sources: Destroyers (DDG 51), Tomahawk Cruise Missile

Installed Combat Systems

The DDG 51 fact file describes the Arleigh Burke class around the integrated Aegis Weapon System, with Aegis Baseline 9 ships adding ballistic-missile-defense capability and Flight III ships centered on enhanced integrated air and missile defense.

Compatible itemItem typeCompatibility evidence
Aegis Combat System, Shipboard integrated combat system, Naval SystemsAegis Combat SystemShipboard integrated combat system

The Navy describes the Arleigh Burke class as built with the integrated Aegis Weapon System; the Aegis fact file also ties Flight III destroyers to Aegis Baseline 10 integration.

Sources: Destroyers (DDG 51), AEGIS Weapon System

Timeline

Arleigh Burke-class guided-missile destroyer Key Events

  1. Lead ship enters service

    The Navy fact file lists USS Arleigh Burke (DDG 51) as deployed on July 4, 1991, establishing the class in U.S. Navy service.

    Sources: Destroyers (DDG 51), AEGIS Weapon System

  2. DDG 51 production resumes

    The Navy's Aegis fact file says the DDG 51 line restarted in fiscal year 2010 to continue production of the platform after the original acquisition program.

    Sources: AEGIS Weapon System

  3. First Flight III keel authenticated

    NAVSEA reported that the future USS Jack H. Lucas (DDG 125) had its keel authenticated as the first Arleigh Burke-class destroyer built in the Flight III configuration.

    Sources: Keel Authenticated for First Flight III Arleigh Burke Class Destroyer

  4. First Flight III ship commissions

    USS Jack H. Lucas (DDG 125) commissioned at Tampa, Florida, bringing the first Flight III, AN/SPY-6(V)1, and Aegis Baseline 10 Arleigh Burke destroyer into commissioned service.

    Sources: USS Jack H Lucas Commissions in the Sun State at Port Tampa Bay
