Hobart-class air warfare destroyer

Also known as
  • Air Warfare Destroyer
  • AWD
  • Hobart-class AWD
  • Hobart-class guided missile destroyer
  • Hobart class destroyer
  • DDG

The Hobart-class air warfare destroyer is Australia's three-ship Aegis-equipped guided-missile destroyer class, adapted from Navantia's F100 design and built in Australia by the Air Warfare Destroyer Alliance. Its public record is strongest as a fleet air-defense, escort, surface-strike, and undersea-warfare platform: the class combines AN/SPY-1D(V), Aegis Baseline 7.1, SM-2, ESSM, Harpoon, helicopter facilities, torpedoes, and a 48-cell Mk 41 vertical launch system, with later Australian test firings adding Naval Strike Missile, SM-6, and Tomahawk integration context.

Role in Conflicts

Side
Unconfirmed conflict context

Exact model: Hobart-class Air Warfare Destroyer, fitted with the Aegis combat system. Australian official and naval sources document trials, exercises, sanctions monitoring, and regional deployments, but not confirmed armed-conflict employment.

Profile / Specs

Profile

Origin
Australia
Type
Guided-missile destroyer
Service note
2017-present
Designer
Navantia
Produced
2012-2020
Number built
3
Developed from
Navantia F100 frigate

Specifications

Displacement
7,000 tonnes full load
Length
146.7 m
Beam
18.6 m
Draught
7.2 m
Speed
28+ knots
Range
4,500 nautical miles at 18 knots
Crew
Approximately 180
Combat system
Aegis Baseline 7.1 with AN/SPY-1D(V) phased-array radar
Vertical launch cells
48-cell Mk 41 Vertical Launch System
Missile fit
SM-2, RIM-162 ESSM, and Harpoon fit documented by the Royal Australian Navy; SM-6, Naval Strike Missile, and Tomahawk test/integration activity documented in 2024
Gun armament
5-inch Mark 45 62-calibre gun plus two 25 mm M242 Bushmaster weapons on Typhoon mounts
Torpedoes
MU90 torpedoes
Countermeasures
Nulka active missile decoy system
Aircraft
One MH-60R Seahawk helicopter
Propulsion
CODOG machinery with two GE LM2500 gas turbines and two Caterpillar Bravo diesel engines
Combat System And Missiles

The Hobart class is built around Aegis-controlled area air defence and a mixed shipboard missile suite, with later Australian test firings documenting added long-range strike and missile-defence weapons.

Carried itemItem typeCarriage evidence
Aegis Combat System, Shipboard integrated combat system, Naval SystemsAegis Combat SystemShipboard combat system

The Royal Australian Navy says Hobart-class DDGs are fitted with the Aegis Combat System.

Sources: HMAS Hobart (III)

Standard Missile-2 (SM-2), Shipboard surface-to-air missile family, MunitionsStandard Missile-2 (SM-2)Surface-to-air missile

The Royal Australian Navy says the Aegis Combat System on Hobart-class DDGs uses the SM-2 missile to engage aircraft and missiles at ranges in excess of 150 km.

Sources: HMAS Hobart (III)

Evolved Sea Sparrow Missile, Ship self-defense missile, MunitionsEvolved Sea Sparrow MissileShip self-defense missile

The Royal Australian Navy lists the RIM-162 Evolved Sea Sparrow Missile among the Hobart-class Mk 41 VLS missile fit.

Sources: HMAS Hobart (III)

Harpoon, Anti-ship cruise missile family, MunitionsHarpoonAnti-ship missile

The Royal Australian Navy lists advanced Harpoon missiles in two quad launchers on the Hobart-class fit.

Sources: HMAS Hobart (III)

Mark 45 5-inch naval gun, Naval gun, ArtilleryMark 45 5-inch naval gunNaval gun

The Royal Australian Navy identifies the Hobart-class main gun as a 5-inch Mark 45 62-calibre gun.

Sources: HMAS Hobart (III)

MH-60R Seahawk helicopter, Primary anti-submarine and surface warfare helicopter, Aircraft & UAVsMH-60R Seahawk helicopterShipboard helicopter

The Royal Australian Navy lists one MH-60R Seahawk as the Hobart-class embarked helicopter.

Sources: HMAS Hobart (III)

Standard Missile-6 (SM-6), Ship-launched multi-mission interceptor missile, Air DefenseStandard Missile-6 (SM-6)Extended-range air and missile defense missile

Australia announced an HMAS Sydney SM-6 firing in 2024 and said SM-6 would be progressively deployed across Hobart-class destroyers.

Sources: Navy conducts firing of Standard Missile 6

BGM-109 Tomahawk Land Attack Missile, Ship- and submarine-launched land-attack cruise missile, MunitionsBGM-109 Tomahawk Land Attack MissileLand-attack cruise missile

Australia announced that HMAS Brisbane fired a Tomahawk missile in 2024 and that acquired Tomahawks would be deployed in Hobart-class destroyers.

Sources: Navy conducts successful firing of Tomahawk cruise missile

Timeline

Hobart-class air warfare destroyer Key Events

  1. HMAS Hobart laid down

    The Royal Australian Navy says HMAS Hobart was laid down on 6 September 2012.

    Sources: HMAS Hobart (III)

  2. HMAS Hobart launched

    The Navy says Hobart was launched on 23 May 2015.

    Sources: HMAS Hobart (III)

  3. First ship accepted by Defence

    Defence marked provisional acceptance of the first Air Warfare Destroyer at Osborne Naval Shipyard.

    Sources: Defence accepts delivery of first Air Warfare Destroyer Hobart

  4. HMAS Hobart commissioned

    The Navy commissioned HMAS Hobart on 23 September 2017, bringing the first ship of the class into service.

    Sources: HMAS Hobart (III)

  5. HMAS Brisbane commissioned

    The Sea Power Centre records HMAS Brisbane as the second Hobart-class guided-missile destroyer and gives its commissioning date as 27 October 2018.

    Sources: HMAS Brisbane (III)

  6. HMAS Hobart fires SM-2 in Australian waters

    The Defence Ministers office said HMAS Hobart became the first Hobart-class destroyer to fire a missile in Australian waters when it launched an SM-2 during trials off New South Wales.

    Sources: HMAS Hobart strikes in Australian-first missile firing

  7. HMAS Sydney commissioned

    The Sea Power Centre records HMAS Sydney as the third and final Hobart-class guided-missile destroyer and gives its commissioning date as 18 May 2020.

    Sources: HMAS Sydney (V)

  8. HMAS Hobart fires during RIMPAC

    U.S. Third Fleet reported that HMAS Hobart fired an SM-2 Standard Missile against an unmanned target during RIMPAC 2020.

    Sources: HMAS Hobart successfully fires missile during its first RIMPAC

  9. Class reaches final operational capability

    Defence said the Hobart-class Air Warfare Destroyers reached final operational capability after HMAS Sydney completed test and evaluation off the United States and Canada.

    Sources: Advanced warships ready for operations

  10. HMAS Sydney fires Naval Strike Missile

    The Defence Ministers office said Hobart-class destroyer HMAS Sydney conducted a Naval Strike Missile firing during Exercise RIMPAC 2024 as part of enhanced surface-combatant strike integration.

    Sources: Navy conducts successful firing of Naval Strike Missile

  11. HMAS Sydney fires SM-6

    Australia announced that HMAS Sydney had conducted a Standard Missile 6 firing near Hawaii and that SM-6 would be progressively deployed across Hobart-class destroyers.

    Sources: Navy conducts firing of Standard Missile 6

  12. SM-2 IIIC and SM-6 acquisition announced

    The Australian Government announced a $7 billion acquisition of SM-2 Block IIIC and SM-6 missiles for Hobart-class destroyers and future Hunter-class frigates.

    Sources: Safeguarding Australians with boost to air and missile defence

  13. HMAS Brisbane fires Tomahawk

    HMAS Brisbane, a Hobart-class destroyer, fired a Tomahawk missile off the west coast of the United States during test and evaluation activity.

    Sources: Navy conducts successful firing of Tomahawk cruise missile
