M549A1 rocket-assisted projectile

Also known as
  • M549A1 RAP
  • M549A1 HE RAP
  • M549A1 HE-RAP
  • 155 mm M549A1 HE-RAP
  • M549A1 Rocket Assisted Projectile

The M549A1 is a U.S. 155 mm high-explosive rocket-assisted projectile and the TNT-filled follow-on to the earlier Composition-B-filled M549. Army references describe it as a two-piece round with a high-fragmentation steel warhead and integral rocket motor, built to extend howitzer range to about 30 km and later treated as a legacy munition for replacement by XM1113. Conflict reporting also places M549A1 RAP in Ukrainian Bohdana howitzer combat use during the 2014 Russia-Ukraine War.

M549A1 rocket-assisted projectile, 155 mm high-explosive rocket-assisted projectile, Munitions
Image source: File:Sweeping without a broom 131029-M-Zs544-486.jpg

Role in Conflicts

Profile / Specs

Profile

Origin
United States
Type
155 mm high-explosive rocket-assisted projectile
Service note
Type-classified in 1977; legacy 1970s-1980s U.S. ammunition
Produced
Late 1970s-1980s

Specifications

Caliber
155 mm
Type
High-explosive rocket-assisted projectile
Weight
96 pounds
Payload
15 pounds of TNT
Maximum range
30 km from M198 and similar 155 mm systems
Propelling charges
M203A1, M119A2, MACS M232/M232A1, and/or M4A2
Rocket motor
About 6.5 pounds of solid rocket propellant
Construction
Two preassembled components: high-explosive warhead and rocket motor
Round Architecture And Designation

The A1 designation matters because public sources distinguish it from the earlier M549 by explosive fill and charge-safety context rather than by a new caliber or launcher class.

FeatureM549 contextM549A1 treatment
Explosive fillEarlier M549 rounds used Composition B.M549A1 uses about 15 pounds of TNT.
Type-classification driverThe earlier fill was restricted with newer top-zone M203 propelling-charge use.The A1 conversion was type-classified in September 1977 to satisfy safety requirements for newer 155 mm weapon systems.
Range roleBoth belong to the U.S. 155 mm rocket-assisted projectile family.M549A1 keeps the extended-range role with a high-explosive warhead and integral rocket motor.

Sources: M549A1 Rocket Assisted Projectile; PEO Ammunition 2017.

Firing Weapons

Army ammunition references and conflict reporting tie this legacy 155 mm projectile to U.S. howitzers and compatible NATO-standard systems.

Firing weaponWeapon typeFiring evidence
2S22 Bohdana, 155 mm wheeled self-propelled howitzer, Artillery2S22 Bohdana155 mm wheeled self-propelled howitzer

Army Recognition lists M549A1 RAP among the NATO-standard shells confirmed in combat use by Ukrainian Bohdana howitzers.

Sources: Bohdana 5.0 M549A1 combat-use report

M777, 155 mm towed howitzer, ArtilleryM777155 mm towed howitzer family

The Army ammunition portfolio identifies M549A1 compatibility with M777-series 155 mm field artillery.

Sources: PEO Ammunition 2017

M198 155 mm howitzer, 155 mm towed howitzer, ArtilleryM198 155 mm howitzer155 mm towed howitzer

Army ammunition data use M198-class firing tables for the round's roughly 30 km maximum range.

Sources: PEO Ammunition 2017, M549A1 Rocket Assisted Projectile

M109A6 Paladin, 155 mm tracked self-propelled howitzer, ArtilleryM109A6 Paladin155 mm self-propelled howitzer

The Army ammunition portfolio places M549A1 in the 155 mm ammunition set for M109A6 Paladin-era field artillery.

Sources: PEO Ammunition 2017

FH70 155 mm howitzer, 155 mm towed howitzer, ArtilleryFH70 155 mm howitzer155 mm towed howitzer

GlobalSecurity lists the M549A1 rocket-assisted projectile as ammunition for the FH-70 howitzer.

Sources: FH-70 - 155mm Howitzer

Timeline

M549A1 rocket-assisted projectile Key Events

  1. M549A1 type-classified

    The A1 conversion replaced the earlier M549 Composition B fill with TNT to meet safety requirements for newer 155 mm weapon and charge combinations.

    Sources: M549A1 Rocket Assisted Projectile

  2. XM1113 replacement effort described

    A U.S. Army article identified XM1113 as the planned successor to aging M549A1 RAP stocks produced in the 1970s and 1980s.

    Sources: Army developing safer, extended range rocket-assisted artillery round

  3. Reported in Bohdana combat use

    Army Recognition listed M549A1 RAP among the NATO-standard shells confirmed in combat use by Ukrainian Bohdana howitzers.

    Sources: Bohdana 5.0 M549A1 combat-use report
