SA 330 Puma

Also known as
  • Aérospatiale SA 330 Puma
  • Aerospatiale SA 330 Puma
  • Sud Aviation SA 330 Puma
  • SA330 Puma
  • SA-330 Puma
  • Puma HC Mk 1
  • Puma HC.Mk 2
  • Westland Puma
  • IAR 330 Puma
  • SA 330S Puma

The SA 330 Puma is a French-designed twin-engine medium-lift helicopter family built for troop transport, casualty evacuation, logistics, search-and-rescue, and utility missions. Cataloged conflict rows cover Argentine Puma use in the Falklands War, RAF support-helicopter use in the Gulf, Afghanistan, and Iraq, plus Portugal's late-2024 transfer of stored Puma helicopters to Ukrainian forces, while the record separates the original SA 330 family from the later Super Puma/Cougar successor page.

Role in Conflicts

Profile / Specs

Profile

Origin
France
Type
Twin-engine medium-lift utility helicopter
Service note
Cold War medium-lift design retained in modern military utility and aid-transfer service
Designer
Sud Aviation
Designed
1960s
Produced
1968-1987 for the original SA 330 production family
Developed into
AS332 Super Puma

Specifications

Crew and passenger load
SA 330H reference data lists 3 crew and 16 passengers; RAF HC2 guidance lists 16 passengers or 12 fully equipped troops
Medical evacuation fit
RAF HC2 guidance says up to six stretchers can be fitted for casualty evacuation or medical emergency response
Freight payload
RAF HC2 guidance lists up to 4,400 lb (2,000 kg) of freight carried internally or underslung
Powerplant
2 x Turbomeca Turmo IVC turboshafts, 1,175 kW (1,575 hp) each in SKYbrary SA-330 technical data
Rotor configuration
Four-blade main rotor and five-blade tail rotor
Length
18.15 m in SKYbrary SA-330 data; RAF HC2 lists 18.20 m overall
Main rotor diameter
15.00 m in SKYbrary SA-330 data; RAF HC2 lists 15.09 m
Maximum takeoff weight
7,400 kg in SKYbrary indicative SA-330 data
Cruise speed
140 kt in SKYbrary indicative SA-330 data
Range
300 nautical miles in SKYbrary indicative SA-330 data
Armament fit
RAF HC.Mk 2 specification lists two 7.62 mm GPMGs
Mission Fit

The SA 330 family is best treated as a support helicopter rather than a dedicated attack platform. RAF material describes the Puma HC2 in tactical troop movement, weapons and ammunition movement, stores transport, casualty extraction, medical emergency response, non-combatant evacuation, humanitarian relief, and disaster-relief roles.

Tactical movement

RAF payload guidance lists 16 passengers, 12 fully equipped troops, or up to 2 tonnes of freight carried internally, underslung, or in a mixed load.

Medical evacuation

The same RAF capability summary says the aircraft can be fitted with up to six stretchers for casualty-evacuation or medical emergency response missions.

Falklands record

Specialist and museum sources document Argentine SA330L/SA330 use, losses, and capture evidence in the 1982 Falklands War.

Gulf War lift

RAF Operation Granby coverage says Pumas inserted British Special Forces behind Iraqi lines and later delivered food and aid to displaced refugees.

Afghanistan transport

RAF reporting says Pumas based at Kabul International Airport moved personnel and equipment around urban, mountainous, and desert terrain for UK and NATO forces.

Iraq troop delivery

Hansard records Puma ZA938 supporting UK operations in Iraq as part of a formation delivering troops to a landing site in November 2007.

Ukraine aid context

The Ukraine row records transfer to Ukraine, not independently verified combat sorties by Ukrainian SA 330 crews.

Sources: RAF Puma HC2; SA330L Puma in Aviacion de Ejercito Argentino; The Helicopter Museum Falklands War; RAF Operation Granby Puma Sorties; RAF Puma Afghanistan Return; RAF Puma ZA938 Board of Inquiry; Portugal Military Support to Ukraine; Defense Express Portugal SA 330 Puma Delivery.

Family Boundary

This page covers the original SA 330 Puma line, including Westland-built RAF Pumas and license/upgrade branches such as IAR 330 references. The later Super Puma combat-support family is represented by a separate linked catalog record because its conflict evidence and specifications are materially different.

Original Puma

SKYbrary identifies the Aérospatiale SA-330 Puma as a four-blade, twin-engine medium transport/utility helicopter originally manufactured by Sud Aviation.

RAF branch

Westland production and later HC.Mk 2 upgrades make the British Puma branch prominent, but it remains part of the SA 330 family lineage.

Successor page

Use the Super Puma combat-support helicopter entry for later-family conflict rows rather than attaching them to this original SA 330 page.

Sources: SKYbrary SA-330 Puma; RAF Puma HC2.

Variants

The record covers the original SA 330 Puma family and license/upgrade branches, not the later AS332 Super Puma successor family except as a linked successor.

VariantConfigurationDesignation notes
SA 330BFrench Army production branch

The SA 330 design entered French and export service as a medium utility helicopter before later derivative families appeared.

Sources: RAF Puma HC2

SA 330E / Puma HC Mk 1Westland-built RAF branch

The RAF history says Westland built 48 Puma HC Mk 1 aircraft after an initial SA330 delivery to the United Kingdom.

Sources: RAF Puma HC2

Puma HC.Mk 2Upgraded RAF support-helicopter configuration

The RAF describes the HC.Mk 2 as a major upgrade of 24 airframes with Makila engines, digital avionics, secure communications, improved self-protection, and greater range than the HC.Mk 1.

Sources: RAF Puma HC2

IAR 330 PumaRomanian license-production and modernization branch

IAR says it produced Puma helicopters under Aerospatiale license and lists IAR330 Puma modernization programs including SOCAT, SM, Naval, NATO, and VIP configurations.

Sources: IAR General Information, SKYbrary SA-330 Puma

Super Puma combat support helicopter, Twin-engine medium-lift utility helicopter, Aircraft & UAVsSuper Puma combat support helicopterSuccessor family

The linked catalog entry covers the later Super Puma combat-support branch rather than the original SA 330 airframe.

Sources: RAF Puma HC2

Carried Armament

The SA 330 family is primarily a support-helicopter line; the documented RAF HC.Mk 2 armament fit is a defensive machine-gun installation rather than a dedicated attack-helicopter package.

Carried itemItem typeCarriage evidence
7.62 mm machine gun, Belt-fed general-purpose / vehicle-mounted 7.62 mm machine gun class, Infantry Weapons7.62 mm machine gunDefensive machine-gun fit

The RAF Puma HC.Mk 2 specification lists two 7.62 mm GPMGs.

Sources: RAF Puma HC2

Timeline

SA 330 Puma Key Events

  1. SA300 basis becomes the SA330 line

    RAF type history says Sud-Aviation developed the SA300 medium transport helicopter in 1965 and that it formed the basis of the SA330 Puma.

    Sources: RAF Puma HC2

  2. First SA330 arrives in the United Kingdom

    The RAF history records an SA330 delivery to the United Kingdom in 1968, followed by Westland production of Puma HC Mk 1 aircraft.

    Sources: RAF Puma HC2

  3. RAF squadron service begins

    The RAF says the Puma entered service with 33 Squadron in June 1971 and with 230 Squadron in January 1972.

    Sources: RAF Puma HC2

  4. Argentine Pumas documented in the Falklands War

    Helis.com records Argentine Army SA330L Puma losses during the Malvinas/Falklands War, while The Helicopter Museum describes an Argentine Coast Guard SA330 damaged, abandoned, and captured near Port Stanley.

    Sources: SA330L Puma in Aviacion de Ejercito Argentino, The Helicopter Museum Falklands War

  5. Pumas support Operation Granby

    RAF anniversary coverage says Puma helicopters from the Helicopter Support Force flew missions to insert British Special Forces behind Iraqi lines during Operation Granby and later helped deliver food and aid to displaced refugees.

    Sources: RAF Operation Granby Puma Sorties

  6. RAF Pumas documented in Iraq

    UK Ministry of Defence and Hansard records document RAF Puma losses and troop-delivery support in Iraq during 2007.

    Sources: UK MOD Puma Helicopters Iraq Fatality Notice, RAF Puma ZA938 Board of Inquiry

  7. Puma HC.Mk 2 returns to full RAF service

    After Eurocopter upgraded 24 RAF airframes, the RAF says the Puma HC.Mk 2 returned to full operational service in 2015.

    Sources: RAF Puma HC2

  8. RAF Puma detachment begins Kabul deployment

    RAF reporting says three Puma helicopters began serving in Kabul in March 2015 as part of Operation TORAL and the NATO Resolute Support Mission.

    Sources: RAF Puma Afghanistan Return

  9. Portuguese Puma helicopters delivered to Ukraine

    Portugal's Ukraine-support list places Puma helicopter deliveries in the fourth quarter of 2024; Defense Express identifies the package as eight SA 330 Pumas.

    Sources: Portugal Military Support to Ukraine, Defense Express Portugal SA 330 Puma Delivery

  10. RAF Puma retirement window

    The RAF aircraft page said the Puma would remain in RAF service until March 2025, while BFBS reported farewell flypasts at the end of March 2025.

    Sources: RAF Puma HC2, BFBS RAF Puma Farewell
