DVIDS reporting from Helmand Province documents U.S. Marines firing a MK-19 grenade launcher from an observation post during a July 2011 firefight near Gereshk.
Role detailsInfantry Weapons
40 mm automatic grenade launcher
Also known as
- Mk-19 grenade launcher
- Mark 19 grenade machine gun
- Mark 19 grenade launcher
- Mk 19
- Mk 19 Mod 3
- MK19 grenade machine gun
- 40AGL Mk2
- CIS 40AGL
- STK 40 AGL
- SB-40 LAG
- LAG 40
- HK GMG
- Heckler & Koch GMG
- GMW
The 40 mm automatic grenade launcher class covers belt-fed crew-served grenade machine guns such as the U.S. Mk 19 Mod 3, ST Engineering 40AGL Mk2, Heckler & Koch GMG, and Spain's LAG 40 family. Direct reporting documents Mk 19 use by U.S. forces in Afghanistan and Iraq, coalition partner training against Islamic State, and Ukrainian frontline employment in the Russia-Ukraine War.
Role in Conflicts
DVIDS reporting documents U.S. soldiers employing a MK-19 automatic grenade launcher during a March 2008 firefight in Jisr Diyala, Iraq.
Role detailsDVIDS documents an Iraqi Counter-Terrorism Service trainee firing a MK-19 near Baghdad under CJTF-OIR partner-force training against ISIL, and a 2020 coalition Mark 19 live-fire exercise at Al Asad Air Base in Iraq.
Role details- Side
- Ukraine
Militarnyi reported that Mk 19 grenade launchers were already in Ukrainian Defense Forces frontline units in 2023, and later reporting tied Mk-19 or AGL-53 integration to Ukrainian robotic fire-support systems.
Role detailsProfile / Specs
Profile
- Origin
- Multiple countries
- Built by
- General Dynamics Ordnance and Tactical SystemsU.S. OrdnanceST EngineeringHeckler & KochMKE, Sarsilmaz, KalekalipVarious manufacturers
- Type
- 40 mm automatic grenade launcher
- Service note
- Cold War-era class still in service
- Designer
- Multiple designers
- Designed
- 1960s-present
- Unit cost
- $18,000 (FY 2008 Army procurement unit cost)
- Produced
- 1968-present
Specifications
- Caliber
- 40x53 mm high-velocity class for Mk 19-type launchers; other 40 mm AGLs vary by model
- Feed
- Disintegrating-link or belt-fed depending on model
- Mounting
- Tripod, vehicle, remote weapon station, ring, soft, cupola, or naval/marine craft mount depending on model
- Role
- Crew-served support fire
- Ammunition
- 40 mm high-velocity grenades, including M430A1 HEDP rounds
- Mk 19 cyclic rate
- 325-375 rounds per minute
- Mk 19 maximum range
- 2,212 m
- Mk 19 effective range
- 1,500 m against point/soft targets; U.S. Ordnance also lists 2,000 m against area targets
- Mk 19 weight
- 77.6 lb / 35 kg without mount
- GMG example
- 40x53 HV, 32-round ammunition box, 340 rounds/min, left- or right-side belt feed, and 1,500 m effective range
- Ammunition cost
- Tactical 40 mm rounds reported at $50 or $60 each; day training rounds about $7
Ammunition Context
Most Mk 19-type automatic grenade launchers use linked 40x53 mm high-velocity ammunition rather than the lower-velocity 40x46 mm rounds fired by shoulder or under-barrel grenade launchers. U.S. Army acquisition reporting identifies M430A1 HEDP as the primary high-velocity tactical round for Mk 19 grenade machine guns, and U.S. Ordnance lists M430A1 among the rounds fired by the MK19 MOD 3.
High-velocity family
40x53 mm linked ammunition for automatic launchers such as Mk 19, Mk 47, HK GMG, and Vektor Y3 AGL.
Representative tactical round
M430A1 HEDP, described by Army acquisition reporting as the primary 40 mm HV tactical cartridge.
40 mm AGL Family Comparison
The main Western 40 mm automatic grenade launcher families share a crew-served support role, but differ in feed direction, operating system, weight, and mounting options.
| Family | Feed / mount | Source-backed distinction |
|---|---|---|
| Mk 19 Mod 3 | Tripod or vehicle | U.S. Army and U.S. Ordnance list a 77.6 lb 40 mm grenade machine gun with 1,500 m point-target range and 2,212 m maximum range. |
| CIS / STK 40AGL | Belt-fed; tripod, vehicle, marine craft, cupola | Army Guide supports the Singapore family background and its vehicle or marine-craft mounting context. |
| LAG 40 SB | Linked feed; tripod, vehicle, craft, helicopter | Army Guide lists the LAG 40 as a belt-fed 40x53 mm automatic grenade launcher with 1,500 m effective range. |
| Heckler & Koch GMG | Left/right belt feed; remote or vehicle station | H&K lists 40x53 HV ammunition, semi-automatic or full-automatic fire, 32-round ammunition box, 340 rpm rate of fire, and 1,500 m effective range. |
Variants
This class page groups comparable 40x53 mm automatic grenade launcher families rather than treating every model as one lineage.
| Variant | Configuration | Designation notes |
|---|---|---|
| Mk 19 Mod 3 | U.S. 40x53 mm grenade machine gun | U.S. Army and U.S. Ordnance data describe the Mk 19 Mod 3 as a belt-fed, blowback-operated, air-cooled 40 mm grenade machine gun with a 325-375 rpm cyclic rate. |
| 40AGL Mk2 | Singapore 40 mm automatic grenade launcher | ST Engineering describes the 40AGL Mk2 as a high-velocity 40 mm launcher with modular assembly and sight or mount options including reflex sight, lock-and-fire mount, and softmount. Sources: ST Engineering 40AGL Mk2 |
| CIS 40AGL / STK 40 AGL | Earlier Singapore 40 mm AGL family | Army Guide's CIS 40AGL profile supports the Singaporean family background and its vehicle or marine mounting context. |
| LAG 40 / SB-40 LAG | Spanish 40x53 mm automatic grenade launcher | Army Guide lists the LAG 40 as a belt-fed 40x53 mm automatic grenade launcher with an effective range of 1,500 m. |
| Heckler & Koch GMG | German 40x53 mm grenade machine gun | Heckler & Koch describes the GMG as a 40x53 HV support weapon with belt-linked ammunition, semi-automatic or full-automatic fire, left- or right-side belt feed, and 1,500 m effective range. Sources: GMG | Heckler & Koch |
Mounted Platforms
Army and partner reporting document vehicle mounts for the 40 mm family, including the HMMWV and the Al-Shibl 2.
| Carrier | Carrier type | Carriage evidence |
|---|---|---|
 | Light tactical vehicle | Army Reserve Cold Steel says soldiers train and qualify on the MK19 grenade launcher on mounted and dismounted military platforms, including the HMMWV. Sources: Cold Steel mounted weapons |
 | Light armored personnel carrier | Army Guide explicitly lists a multi-weapon ring mount on the Al-Shibl 2 that accepts a 40 mm grenade launcher. Sources: Al Shibl 2 |
 | High-speed assault and landing craft | The BK-16 ship-specifications PDF lists a 40 mm automatic antipersonnel grenade-launcher complex among the boat's armament options. |
Compatible Triggers
DevDroid lists an electric trigger as compatible with Mk-19, and Frontline Robotics describes Mk 19 as part of a launcher family that uses electric trigger systems for remote control.
| Compatible item | Item type | Compatibility evidence |
|---|---|---|
 | Electric trigger | DevDroid lists the electric trigger as compatible with Mk-19, and Frontline Robotics describes Mk 19 as part of a launcher family that uses electric trigger systems for remote control. Sources: DevDroid product page, Frontline Robotics BURIA 2.0 article |
Carrier Vehicles
The Cougar MRAP can be fitted with a roof-mounted 40 mm automatic grenade launcher.
| Carrier | Carrier type | Carriage evidence |
|---|---|---|
 | Mine-resistant ambush-protected vehicle | Army Recognition says the Cougar MRAP roof can be fitted with an open-top weapon station or a remotely controlled weapon station armed with a 40 mm automatic grenade launcher. Sources: Poland signs contract to purchase 300 second-hand Cougar MRAP vehicles from US |
Timeline
40 mm automatic grenade launcher Key Events
MK-19 used in Jisr Diyala firefight
DVIDS reporting describes U.S. soldiers employing a MK-19 automatic grenade launcher during a March 2008 firefight in Iraq.
MK-19 fires from Helmand observation post
DVIDS reporting from Helmand Province documents U.S. Marines using a MK-19 during an engagement near Gereshk, Afghanistan.
Partner-force MK-19 training against ISIL
A DVIDS image record documents an Iraqi Counter-Terrorism Service trainee firing a MK-19 near Baghdad during CJTF-OIR training.
Ukrainian frontline Mk 19 sights delivered
Militarnyi reported that 60 special sights for Mk 19 launchers had reached Ukrainian Defense Forces units at the frontline.
