Documented in Saudi/UAE-led coalition airstrikes in Hajjah governorate in 2015-2016, where remnants were identified as SUU-30H/B dispensers from CBU-52B/B and CBU-58A/B or likely CBU-58 cluster bomb units.
Role detailsMunitions
SUU-30H/B dispenser
Also known as
- SUU-30H/B
- SUU-30-series dispenser
- SUU-30( )/B
The SUU-30H/B is a U.S.-origin, fin-stabilized submunition dispenser in the broader SUU-30 family, built as the cargo body for air-dropped cluster bomb units. METIS and OSMP link the H/B dispenser to CBU-52B/B, CBU-58/B or CBU-58A/B, and CBU-71/B configurations, while OSMP records identify SUU-30H/B remnants from Saudi/UAE-led coalition airstrikes in Yemen.
Role in Conflicts
Profile / Specs
Profile
- Origin
- United States
- Built by
- Milan Army Ammunition Plant
- Type
- Air-delivered submunition dispenser
- Service note
- Cold War design documented in Yemen conflict use after 2015
- Designed
- 1960s SUU-30 series development; SUU-30/B family in U.S. service from the 1970s
- Produced
- 1970s production; OSMP documents a CBU-52B/B SUU-30H/B lot marking interpreted as Milan Army Ammunition Plant manufacture in July 1977
Specifications
- Dispenser type
- Bomb-shaped, fin-stabilized, two-part aerial submunition dispenser
- Compatible cluster bomb units
- CBU-52B/B, CBU-58/B or CBU-58A/B, and CBU-71/B series configurations, with H/B-specific evidence strongest where OSMP or METIS names SUU-30H/B
- Representative payloads
- 217 BLU-61A/B submunitions in CBU-52B/B; 650 BLU-63/B or BLU-63A/B submunitions in CBU-58 series; CBU-71/B uses a BLU-86/B payload, with open sources differing between 650 and 670 submunitions
- Guidance
- Unguided air-to-surface munition dispenser
- Related SUU-30B/B dimensions
- Designation-Systems gives the related SUU-30B/B as about 2.1 m long and 41.1 cm in diameter, and describes SUU-30H/B as similar except for tailfin tip-plate layout
- CBU-58A/B explosive fill
- OSMP notes 163 lb (about 74 kg) total COMP B explosive in BLU-63A/B submunitions for a documented Yemen CBU-58A/B remnant
- Compatible fuzes
- JMU's Iraq ordnance guide lists FMU-105A/B, FMU-110/B, FMU-26-series, and FMU-56-series fuzes with SUU-30H/B-associated CBU-58 and CBU-71 systems
Variants
Designation-Systems describes SUU-30H/B as a blunt-nosed SUU-30-family dispenser closely related to SUU-30B/B, with a different tailfin tip-plate layout.
- Related SUU-30B/B blunt-nosed dispenser
Cluster Bomb Configurations
Open-source munition records identify the SUU-30H/B as the dispenser body in CBU-series cluster bomb configurations.
| Compatible item | Item type | Compatibility evidence |
|---|---|---|
 | Air-delivered cluster bomb | OSMP identifies a Yemen remnant as an SUU-30H/B dispenser that comprised a CBU-58A/B, and METIS lists SUU-30H/B as part of CBU-58/B configurations. Sources: OSMP 1545 CBU-58A/B SUU-30H/B Yemen Entry, METIS SUU-30H/B Munition Record |
Submunition Payloads
The dispenser's battlefield effect came from the bomblets released after the cluster bomb opened in flight.
| Carried item | Item type | Carriage evidence |
|---|---|---|
 | High-explosive fragmentation submunition | OSMP states the CBU-58A/B SUU-30H/B remnant carried 650 BLU-63A/B submunitions, while the USMC reference lists CBU-58 as an SUU-30 load with 650 BLU-63 bomblets. Sources: OSMP 1545 CBU-58A/B SUU-30H/B Yemen Entry, MCWP 3-16 Cluster Bomb Reference Data |
Timeline
SUU-30H/B dispenser Key Events
SUU-30 family enters U.S. service
Designation-Systems describes the SUU-30/B series as a U.S. Air Force general-purpose submunition dispenser family used from the 1970s to the 1990s.
Sources: Designation-Systems SUU-30 Series Listing
Milan lot marking documented
OSMP records a Yemen CBU-52B/B remnant with SUU-30H/B markings and a lot number interpreted by ARES as Milan Army Ammunition Plant production in July 1977.
Sources: OSMP 1555 CBU-52B/B SUU-30H/B Yemen Entry
CBU-58A/B remnant identified in Hajjah
OSMP identifies an SUU-30H/B remnant from a CBU-58A/B after a Saudi/UAE-led coalition cluster-bomb attack in Bani Haddad, Hajjah governorate.
Sources: OSMP 1545 CBU-58A/B SUU-30H/B Yemen Entry
Likely CBU-58 strike remnant recorded
OSMP records SUU-30H/B tail-fin section remnants at Al-O'saila in Haradh district after a likely U.S.-made CBU-58 attack by Saudi/UAE-led coalition jets.
Sources: OSMP 1554 SUU-30H/B Yemen Entry
CBU-52B/B remnant identified in Al-Sir
OSMP identifies SUU-30H/B markings from a CBU-52B/B dropped by Saudi/UAE-led coalition jets in Al-Sir village, Hajjah governorate.
Sources: OSMP 1555 CBU-52B/B SUU-30H/B Yemen Entry, OSMP 1556 CBU-52B/B SUU-30H/B Yemen Entry
Media
SUU-30H/B dispenser Images
Related Weapon Systems
Sources
