Naval Systems

Project 58181 / Project 58503 Centaur-LK fast assault craft

Also known as
  • Project 58181
  • Project 58181 Centaur
  • Project 58503
  • Project 58503 Centaur-LK
  • Centaur class
  • Centaur-LK
  • Kentavr
  • Kentavr-LK
  • Kentaivr-LK
  • Кентавр
  • Кентавр-ЛК

Project 58181 Centaur began as a Ukrainian armored landing-craft design derived from the Gyurza-M gunboat lineage and was revised during construction into Project 58503 Centaur-LK. Built at Kuznya na Rybalskomu for the Ukrainian Navy, the class combines a bow-ramp troop compartment, waterjet propulsion, armored crew and landing spaces, remote weapon stations, 80 mm rocket launchers, and wartime use as a small assault, evacuation, minelaying, and fire-support craft.

Role in Conflicts

Documented Wartime Tasks

The public wartime record is centered on a Ukrainian Navy/Bryz report summarized by Defence Express and expanded by Ukrainian Military Pages. It identifies a Centaur-LK boat in combat service rather than only in trials or procurement reporting.

Landing and withdrawal

The boat was credited with multiple troop landings or evacuations during southern de-occupation operations and with firing in support of troops during insertions and withdrawals.

Minelaying and rescue

Mission markings and Ukrainian reporting point to mine-barrier work and one search-and-rescue operation under combat conditions.

Air-defense improvisation

The crew reportedly used portable air-defense missiles carried on board to shoot down two Russian cruise missiles.

Profile / Specs

Profile

Origin
Ukraine
Type
Armored fast assault / landing craft
Service note
2010s-present
Designer
State Research and Design Shipbuilding Center / Kuznya na Rybalskomu revised Project 58503 design
Designed
2015-2018
Produced
2016-2022
Number built
Two launched in 2018 and a third hull documented as entering Ukrainian Navy service after Russia's 2022 full-scale invasion; earlier plans called for eight boats
Developed from
Project 58155 Gyurza-M armored gunboat lineage

Specifications

Displacement
53 tons full displacement for Project 58503 Centaur-LK; the original Project 58181 concept was listed at 47 tons
Length
24.3 m
Beam
4.8 m
Draft
1.2 m maximum for Project 58503; 1.0 m listed for the original Project 58181 concept
Endurance
5 days
Crew
5 on Project 58503; 4 listed for the original Project 58181 concept
Landing force
Up to 36 troops in the Project 58503 specification; earlier Project 58181 data listed 26-28 troops
Propulsion
2 Caterpillar diesel engines driving 2 Hamilton Jet waterjets
Speed
At least 40 knots for Project 58503; earlier Project 58181 data listed at least 35 knots
Range
At least 500 miles
Armament
80 mm S-8 rocket launcher installation, two light remote weapon modules with 12.7 mm machine guns and UAG-40 grenade launchers, Igla-type MANPADS, smoke launchers, and mine-laying devices
Sensors
Navigation radar, electro-optical fire-control system, and laser-warning sensors
Protection
Armored wheelhouse, engine room, and landing compartment; bow ramp for troop landing
Design Lineage and Layout

Centaur sits between a small armored gunboat and a landing craft. The original Project 58181 design came from the Gyurza-M lineage, while the Project 58503 Centaur-LK boats added a bow ramp, troop compartment, waterjets, armored mission spaces, and a heavier small-craft weapons fit for river and littoral assault tasks.

Parent line

Sources describe the design as based on the Project 58155 Gyurza-M armored gunboat family.

Landing function

The craft has a forward ramp and a protected troop compartment for landing marines or special personnel on an unimproved shore.

Weapons fit

The revised Centaur-LK fit combines two light remote weapon modules, an 80 mm S-8 rocket launcher installation, portable air-defense missiles, smoke launchers, and mine-laying provisions.

Variants

The public sources distinguish the original Project 58181 Centaur design from the revised Project 58503 Centaur-LK configuration built by Kuznya na Rybalskomu.

VariantConfigurationDesignation notes
Project 58181 CentaurOriginal landing-assault craft design

Ukrainian Military Pages describes Project 58181 as the SRDSC-designed Centaur concept based on Project 58155 Gyurza-M.

Sources: Ukrainian Military Pages: Project 58181 Centaur

Project 58503 Centaur-LKRevised production configuration

Ukrainian Military Pages says the boats were revised during construction at Kuznya na Rybalskomu and received the new Project 58503 Centaur-LK designation.

Sources: Ukrainian Military Pages: Project 58503 Centaur-LK

L450 StanislavNamed boat

The 2018 Ukrainian Military Pages boat list identifies L450 Stanislav as the second launched Centaur-LK boat with yard number 01033.

Sources: Ukrainian Military Pages: Project 58503 Centaur-LK

L451 MalynNamed boat

The same boat list identifies L451 Malyn as the first launched Centaur-LK boat with yard number 01032.

Sources: Ukrainian Military Pages: Project 58503 Centaur-LK

Timeline

Project 58181 / Project 58503 Centaur-LK fast assault craft Key Events

  1. Centaur concept publicized

    Ukrainian Military Pages described the Project 58181 Centaur landing-assault craft as an SRDSC design based on the Project 58155 Gyurza-M boat.

    Sources: Ukrainian Military Pages: Project 58181 Centaur

  2. First state contract signed

    The Project 58503 overview records the 2016 Ukrainian defense-order contract with Kuznya na Rybalskomu for the first Centaur boats.

    Sources: Ukrainian Military Pages: Project 58503 Centaur-LK

  3. First two hulls laid down

    The first two boats, yard numbers 01032 and 01033, were laid down at Kuznya na Rybalskomu.

    Sources: Ukrainian Military Pages: Project 58503 Centaur-LK

  4. First boat launched in Kyiv

    Naval Today reported the first Centaur-class assault boat launched at Kuznya na Rybalskomu in Kyiv on 14 September 2018.

    Sources: Naval Today: Ukraine launches first Centaur-class assault boat

  5. Third boat entered service after the full-scale invasion

    Ukrainian Military Pages lists the third Centaur-LK hull as entering Ukrainian Navy service in 2022 after Russia's full-scale invasion.

    Sources: Ukrainian Military Pages: Project 58503 Centaur-LK

  6. Wartime missions reported

    Defence Express summarized a Ukrainian Navy/Bryz report on a Centaur-LK boat that conducted troop landings, provided fire support, evacuated another damaged boat, survived missile damage, and reportedly shot down two Russian cruise missiles with portable missiles carried aboard.

    Sources: Defence Express: Missions Performed by Centaur Boats
