La Fayette class frigate

The La Fayette class is France's five-ship multipurpose stealth frigate family, developed by DCN International in Lorient around reduced radar signature, a 125-meter hull, and a small crew for crisis-response and maritime-surveillance work. It later spawned export derivatives for Saudi Arabia, Singapore, and Taiwan.

Profile

Origin
France
Built by
DCN International (now Naval Group)
Type
Multipurpose stealth frigate class
Service note
1996-present
Designer
DCN International
Designed
Late 1980s
Produced
1988-2001
Number built
5 ships
Variants
La Fayette (F710), Surcouf (F711), Courbet (F712), Aconit (F713), Guépratte (F714)

Also Known As

  • FL-3000
  • FLF
  • Frégate légère furtive
  • La Fayette-class frigate

Specifications

Displacement
3,600 tonnes full load
Length
125 meters
Beam
15.4 meters
Draught
4.1 meters
Speed
25 knots maximum
Range
4,000 nautical miles at 15 knots / 9,000 nautical miles at 12 knots
Complement
140
Propulsion
4 SEMT Pielstick 12PA6V280 STC2 diesel engines in CODAD arrangement, 2 shafts, 2 controllable pitch propellers
Sensors
Sea Tiger mk2 air- and surface-search radar, Castor 2J fire control radar, 1229 navigation and helicopter control radars, ARBR 21 radar warning receiver, ARBB33 jammer
Armament
100 mm gun, 8 MM40 Exocet missiles, Crotale CN2 or Sadral/Simbad short-range air-defense launchers, 20 mm guns, and Dagaie decoys
Aviation
Flight deck and hangar for 1 helicopter

Design Snapshot

The class was built for low-signature patrol, escort, crisis response, and maritime surveillance rather than heavy fleet combat.

CharacteristicDocumented fit
Hull125 m length, 15.4 m beam, 4.1 m draught, and about 3,600 tonnes full load.
CrewAbout 140 sailors, reflecting the class's small-crew design goal.
PropulsionFour SEMT Pielstick diesels in CODAD arrangement with two shafts and a 25-knot top speed.
Weapons100 mm gun, eight MM40 Exocet missiles, and Crotale CN2 or Sadral/Simbad short-range air defense launchers.
AviationFlight deck and hangar for a single Panther helicopter or similar 10-ton aircraft.
RefitThree ships received a 2020-2023 modernization program with a hull sonar addition.

Service And Conflict Use

Service History

In service
La Fayette entered French Navy service on 22 March 1996; the class remains in service and three ships were selected for a 2020-2023 renovation program.
Used by
French Navy, Royal Saudi Navy, Republic of Singapore Navy, Republic of China Navy

Conflict Usage

La Fayette-class frigates are publicly documented in French maritime operations connected to Afghanistan, Lebanon evacuation operations, Libya 2011, EU counter-piracy operations off Somalia, and evacuation support during the Yemen conflict.

Timeline

La Fayette class frigate Key Events

  1. French Navy orders the class

    Naval Technology says the French Navy awarded DCN the contracts for the first three La Fayette ships in 1988, with the remaining two ordered later.

    Sources: La Fayette Class Frigate - Naval Technology

  2. Lead ship enters service

    The French Ministry of the Armed Forces says La Fayette was admitted to active service on 22 March 1996.

    Sources: Frégates type La Fayette (FLF) - Ministère des Armées

  3. Final French ship commissioned

    Naval Technology says Guépratte, the last French La Fayette-class ship, was commissioned in November 2001.

    Sources: La Fayette Class Frigate - Naval Technology

  4. Renovation program begins

    The French Ministry of the Armed Forces says three La Fayette-class frigates entered a 2020-2023 renovation program that adds a hull sonar for anti-submarine warfare.

    Sources: Frégates type La Fayette (FLF) - Ministère des Armées
