WP-8z

Also known as

WP-8Z
WP-8z wz. 1960
Wyrzutnia Pociskow Rakietowych WP-8z
Wyrzutnia rakietowa WP-8z
140 mm WP-8z

The WP-8z is a Polish light towed 140 mm multiple rocket launcher developed for airborne forces as an eight-tube counterpart within the M-14 rocket ecosystem. This is a relationship-only record because the cited sources support its identity, specifications, production, and launcher-to-rocket context, not a separate conflict-use row.

WP-8z, 140 mm eight-tube towed multiple rocket launcher, Artillery

Image source: Wikimedia Commons WP-8z Image

Profile / Specs

Profile

Origin: Poland
Built by: Huta Stalowa Wola
Type: 140 mm eight-tube towed multiple rocket launcher
Service note: Cold War Polish airborne rocket-artillery launcher
Designer: Central Scientific Research Artillery Range team at Zielonka, in Polish-language source accounts
Designed: 1959-1960 design period; 1960-1962 prototype period in Polish reference data
Produced: 1964-1965 serial production in Polish reference and museum data
Number built: About 40 launchers in Opisy Broni reporting

Specifications

Caliber: 140 mm
Launch tubes: Eight tubes in two rows of four
Rocket type: Unguided spin-stabilized rockets
Maximum range: 9,800 m in Polish reference data; Defence24 describes the range as more than 9,800 m
Muzzle velocity: 400 m/s in Polish reference data
Barrel length: 1,110 mm in Polish reference data
Travel dimensions: 3.52 m long, 1.615 m wide, and 1.38 m high in Polish reference data
Weight: 750 kg empty and 1,070 kg loaded in Polish reference data
Elevation and traverse: 12 to 50 degrees elevation and 28 degrees horizontal traverse in Polish reference data
Crew: 4
Emplacement time: 2.5 minutes in Polish reference data
Road towing speed: 60 km/h in Polish reference data

Rockets Launched

Public sources place the WP-8z in the same 140 mm spin-stabilized rocket family represented in the catalog by the M-14 rocket record.

Launched item

Item type

Launch evidence

140 mm M-14 rocket, 140 mm unguided artillery rocket, Munitions

140 mm M-14 rocket

140 mm unguided artillery rocket family

Polish WP-8z references describe an eight-tube 140 mm launcher for unguided, spin-stabilized rockets, while the cataloged M-14 record covers the corresponding 140 mm rocket family used by BM-14 and RPU-14 launchers.

Sources: Polish Wikipedia WP-8z, Opisy Broni WP-8z, FAS RPU-14 launcher
