Aircraft & UAVs

MiG-29S

Also known as
  • MiG-29S Fulcrum-C
  • Fulcrum-C
  • MiG-29 9.13S
  • Product 9.13S
  • Izdeliye 9.13S
  • Mikoyan MiG-29S
  • Mikoyan-Gurevich MiG-29S

The MiG-29S is the Product 9.13S branch of the Soviet MiG-29 Fulcrum family, built around the enlarged-spine Fulcrum-C airframe and a weapons-control upgrade that added N019M/N019ME radar-family improvements, RVV-AE/R-77 compatibility in supported fits, higher payload limits, and broader fuel-tank carriage than early MiG-29 variants.

Role in Conflicts

Aviation Safety Network records Ukrainian Air Force MiG-29 9.13 losses during the full-scale phase of the Russia-Ukraine War, and The Aviationist documents Ukrainian MiG-29s returned to service and fighting pro-Russia separatists in 2014; the reviewed sources do not cleanly identify those aircraft as MiG-29S 9.13S upgrades.

Role details
Profile / Specs

Profile

Origin
Soviet Union
Built by
Mikoyan
Type
Light tactical fighter
Service note
Late Cold War Fulcrum-C modernization
Designer
Mikoyan Design Bureau
Designed
Late 1980s upgrade of the MiG-29 9.13 airframe
Produced
Early 1990s for MiG-29S; MiG-29SE export derivative from the mid-1990s
Developed from
MiG-29

Specifications

Crew
1
Length
17.32 m for MiG-29SE in archived RAC MiG data
Wingspan
11.36 m
Height
4.73 m
Radar
N019M/N019ME Topaz family, depending on MiG-29S or MiG-29SE configuration
Sensors
Optical locating/IRST system and helmet-mounted target designation in MiG-29/SE references
Engines
2 x RD-33 series 2/3 afterburning turbofans in archived MiG-29SE data
Normal takeoff weight
15,300 kg for MiG-29SE
Maximum takeoff weight
20,000 kg for MiG-29SE; specialist references cite about 19,700 kg for MiG-29S
Maximum speed
1,500 km/h near ground; 2,400 km/h at altitude in archived MiG-29SE data
Service ceiling
17,750 m for MiG-29SE
Ferry range
1,500 km clean; 2,900 km with three external tanks for MiG-29SE
Hardpoints
6 external stations in archived MiG-29SE data
Maximum external payload
4,500 kg for MiG-29SE; MiG-29S references commonly cite 4,000 kg
Gun
30 mm GSh-301
Air-to-air missiles
R-27, R-73, and RVV-AE/R-77 family compatibility where radar and weapons-control fit supports it
Designation Boundary

Fulcrum-C is not a one-to-one synonym for MiG-29S. The term is applied to the enlarged-spine 9.13 airframe family as well as the later 9.13S upgrade, so wartime 9.13 evidence is treated as Fulcrum-C context rather than proof that every cited aircraft was an exact 9.13S configuration.

9.13 airframe

Enlarged dorsal spine with added fuel and avionics space, commonly reported as Fulcrum-C.

9.13S upgrade

MiG-29S configuration with improved flight-control and weapons-control features, including N019M-family radar changes and supported RVV-AE/R-77 integration.

SE export branch

Export derivative with stronger archived manufacturer data, including N019ME radar and published load, weight, and range figures.

Variants

Public references use Fulcrum-C for both the enlarged-spine MiG-29 9.13 airframe and the later MiG-29S 9.13S upgrade, so this entry separates the airframe lineage from the exact S/SE weapon-control variants.

VariantConfigurationDesignation notes
MiG-29 9.13Fulcrum-C airframe baseline

The 9.13 introduced the enlarged dorsal spine associated with Fulcrum-C airframes, adding space for fuel and avionics including the Gardeniya jammer; it is related to, but not identical with, the MiG-29S 9.13S upgrade.

Sources: MiG Alley MiG-29 variants, Military Aviation MiG-29S Fulcrum-C

MiG-29S / Product 9.13SSoviet improved fighter variant

Specialist sources describe the MiG-29S as a 9.13-based upgrade with revised flight-control logic, N019M radar-family changes, higher permissible angle of attack, and increased external stores capability.

Sources: GlobalSecurity MiG-29S Fulcrum, MiG Alley MiG-29 variants, Military Aviation MiG-29S Fulcrum-C

MiG-29SEExport derivative

Archived RAC MiG data presents the MiG-29SE as an export version with increased internal fuel, upgraded N019ME radar, RVV-AE compatibility, and a 4,500 kg maximum weapon load.

Sources: Archived RAC MiG MiG-29SE

MiG-29, Air defense fighter, Aircraft & UAVsMiG-29Parent Fulcrum family

The broad MiG-29 page remains the catalog's main public record for the Fulcrum family and better-supported Russia-Ukraine War MiG-29 strike adaptations.

Sources: National Museum MiG-29A

MiG-29K, Carrier-based multirole fighter aircraft, Aircraft & UAVsMiG-29KCarrier-based naval branch

The MiG-29K is a separate navalized Fulcrum branch with a distinct carrier-service record in the catalog.

Sources: National Museum MiG-29A

Carried Weapons

This section links only cataloged weapons with a clear existing record; unlinked MiG-29S references also discuss R-27 and RVV-AE/R-77 compatibility where the radar and weapons-control fit supports it.

Carried itemItem typeCarriage evidence
Vympel R-73 short-range air-to-air missile, Short-range infrared-guided air-to-air missile, MunitionsVympel R-73 short-range air-to-air missileShort-range air-to-air missile

National Museum MiG-29 material lists the AA-11 Archer/R-73 family among MiG-29 air-to-air weapons, while MiG-29S/SE references describe the upgraded Fulcrum branch retaining R-73-family compatibility.

Sources: National Museum MiG-29A, Archived RAC MiG MiG-29SE

Timeline

MiG-29S Key Events

  1. MiG-29 First Flight

    The baseline MiG-29 first flew on 6 October 1977, establishing the Fulcrum airframe family later adapted into 9.13, 9.13S, and export branches.

    Sources: National Museum MiG-29A

  2. Fulcrum-C Airframe Enters Production

    Specialist variant references describe the enlarged-spine MiG-29 9.13 Fulcrum-C branch as entering production from 1986.

    Sources: MiG Alley MiG-29 variants, Military Aviation MiG-29S Fulcrum-C

  3. Final Soviet-Service MiG-29S Batch

    GlobalSecurity reports that 16 MiG-29S fighters produced in 1991 became the last aircraft of the type to enter Russian service, with additional unsold aircraft converted toward the MiG-29SE export version.

    Sources: GlobalSecurity MiG-29S Fulcrum

  4. Ukrainian MiG-29 9.13 Loss Recorded

    Aviation Safety Network lists a Ukrainian Air Force MiG-29 9.13 from the 40th Tactical Aviation Brigade lost near Novopil during the full-scale Russia-Ukraine War, a Fulcrum-C airframe data point that does not by itself confirm the MiG-29S 9.13S upgrade.

    Sources: ASN MiG-29 accident database
