Naval Systems

Sea Baby USV

Also known as
  • SeaBaby
  • SBU Sea Baby
  • SSU Sea Baby
  • Sea Baby II
  • Sea Baby 2
  • Sea Baby maritime drone
  • Sea Baby naval drone

Sea Baby is a Ukrainian naval unmanned surface vehicle developed and operated by the Security Service of Ukraine for long-range strike missions in the Black Sea. Official and open-source reporting shows it evolving from an explosive one-way attack craft into a modular USV family with mine-laying, Grad rocket, and KPV/KPVT machine-gun configurations, while Ukrainian sources describe a 1,000-kilometer baseline range and a later 1,500-kilometer class upgraded generation.

Role in Conflicts

Operated by Ukraine's Security Service as a naval unmanned surface vehicle during the 2014 Russia-Ukraine War, including the July 2023 attack on the Crimean Bridge, strikes against Russian naval targets such as Olenegorsky Gornyak and the SIG tanker, and Grad-equipped Sea Baby attacks against Russian positions on the Kinburn Spit reported by United24 and Ukrainian media in May 2024.

Role details
Profile / Specs

Profile

Origin
Ukraine
Type
Naval unmanned surface vehicle
Service note
Introduced during the full-scale 2014 Russia-Ukraine War
Designer
Security Service of Ukraine with civilian engineering support
Designed
Publicly disclosed in 2023
Unit cost
About $221,000 in the 2024 United24 fundraiser
Produced
2023-present
Number built
Not publicly disclosed

Specifications

Crew
Uncrewed, remotely operated
Length
6 m
Width
2 m
Height above waterline
0.6 m
Maximum speed
90 km/h
Range
Up to 1,000 km
Combat load
Up to 850 kg
Engine power
400 hp
Propulsion
Two 200 hp inboard engines driving twin waterjets
Documented payload options
Explosive charge, RPV-16 rockets, MN-103 Manta bottom mines, 122 mm Grad rockets, and 14.5 mm KPVT machine-gun remote weapon station configurations have been reported in open sources
Construction
Hull material described by United24 as difficult to detect by radar
Variants

Sea Baby is documented as a modular SBU unmanned surface vessel family rather than one fixed armament package; the rows separate the main source-backed configurations.

VariantConfigurationDesignation notes
Explosive strike configurationOne-way maritime strike craft

The SBU identified Sea Baby craft in the July 2023 Crimean Bridge attack and in attacks on Russian naval targets including Olenegorsky Gornyak and the SIG tanker.

Sources: Sea drones are a unique SBU development, This is Battleship

Grad-armed Sea Baby drones, Rocket-armed unmanned surface vessel, Aircraft & UAVsGrad-armed Sea Baby drones122 mm rocket-armed configuration

United24 and Ukrainian reporting described Sea Baby craft equipped with Grad systems and used against Russian positions on the Kinburn Spit; the linked catalog record isolates that rocket-armed configuration.

Sources: United24 Sea Baby Grad systems update, Source: SBU has a new weapon - Grad-equipped Sea Baby drones

Mine-laying configurationNaval mine carrier

Covert Shores identifies imagery of Sea Baby carrying two MN-103 Manta bottom mines, with RPV-16 rockets also visible on some mine-carrying fits.

Sources: Ukraine's Sea Baby Maritime Drone (USV)

Sea Baby II machine-gun configurationRemote weapon station configuration

Covert Shores identifies a Sea Baby II hull with radar and a 14.5 mm KPVT gun in a gyrostabilized remote weapon station.

Sources: Ukraine's Sea Baby Maritime Drone (USV)

Upgraded modular generationLonger-range heavy-payload configuration

2025 reporting on an SBU demonstration described upgraded Sea Baby variants with a 1,500 km class range, up to 2,000 kg payload, and rocket-launcher or machine-gun fits.

Sources: Ukraine unveils upgraded 'Sea Baby' drone it says can strike anywhere in the Black Sea, Kyiv Post Sea Baby upgraded variants

Mounted Weapons

Some documented Sea Baby configurations carry mounted weapons instead of only an explosive charge or mine payload.

Carried itemItem typeCarriage evidence
KPV, 14.5 mm heavy machine gun, Infantry WeaponsKPV14.5 mm heavy machine gun

Covert Shores identifies a Sea Baby II hull with radar and a 14.5 mm KPVT gun in a gyrostabilized remote weapon station.

Sources: Ukraine's Sea Baby Maritime Drone (USV)

Timeline

Sea Baby USV Key Events

  1. First public combat use

    The SBU said Sea Baby marine drones were used in the July 2023 attack on the Crimean Bridge and in strikes on Russian naval targets such as Olenegorsky Gornyak and the SIG tanker.

    Sources: Sea drones are a unique SBU development

  2. Sea trials shown publicly

    Wikimedia Commons hosts the SBU sea-trials video published on this date, which shows Sea Baby in operation during January 2024 sea trials and identifies the file as Creative Commons licensed from ssu.gov.ua.

    Sources: Sea Baby unmanned surface vehicle undertaking sea trials.webm

  3. Grad-equipped combat use reported

    United24 reported that SBU Sea Baby boats had been equipped with Grad systems and tested with the Ukrainian Navy against Russian positions on the Kinburn Spit.

    Sources: United24 Sea Baby Grad systems update, Source: SBU has a new weapon - Grad-equipped Sea Baby drones

  4. Upgraded modular version unveiled

    Euronews and Kyiv Post reported that Sea Baby had been expanded to a 1,500-kilometer range and 2,000-kilogram payload class, with demonstration variants fitted with a multiple-rocket launcher and a stabilized machine-gun turret.

    Sources: Ukraine unveils upgraded 'Sea Baby' drone it says can strike anywhere in the Black Sea, Kyiv Post Sea Baby upgraded variants

Documented Configurations

Sea Baby moved quickly from a one-way strike craft into a more modular surface vessel. The table separates the documented configurations so the payload shift is easy to scan.

ConfigurationSource-backed detailWhy it matters
2023 strike craftThe SBU said Sea Baby was used against the Crimean Bridge and Russian naval targets in July 2023.Shows the system was already being used for long-range maritime strike.
Mine and small-rocket fitCovert Shores identifies Sea Baby imagery with MN-103 Manta bottom mines and RPV-16 rockets.Adds a mine-warfare and close-range rocket payload path beyond the explosive charge.
Grad-armed Sea Baby drones, Rocket-armed unmanned surface vessel, Aircraft & UAVsGrad-armed Sea BabyUnited24 and Ukrainian reporting described Sea Baby craft equipped with Grad systems and used against Russian positions on the Kinburn Spit.Demonstrates a rocket-armed coastal strike role from an unmanned surface vessel.
Sea Baby II machine-gun fitCovert Shores identifies a Sea Baby II hull with radar and a 14.5 mm KPVT remote weapon station.Shows a reusable armed USV role suited to engaging surface or aerial threats rather than only ramming targets.
2025 modular upgradeEuronews and Kyiv Post reported a 1,500-kilometer range, 2,000-kilogram payload, and demonstration variants fitted with rocket and machine-gun weapons.Indicates a heavier, longer-range generation with multiple combat configurations.
