PG-7VL rocket-propelled grenade

Also known as
  • PG-7VL
  • PG-7VL Luch
  • PG-7L
  • PG-7L anti-tank grenade
  • PG-7VL round
  • PG-7VL HEAT round

The PG-7VL is a Soviet-origin RPG-7-compatible high-explosive anti-tank round, also associated with the Luch designation and PG-7L grenade. Russian and Bulgarian product sources describe a 93 mm warhead, roughly 2.6 kg round weight, 300 m sighting or effective range, and about 500 mm armor penetration; conflict documentation places PG-7VL projectiles in Islamic State and PKK weapons stocks rather than tying them to a named firing incident.

Role in Conflicts

Profile / Specs

Profile

Origin
Soviet Union
Built by
BazaltVMZ Sopot
Type
RPG-7-compatible HEAT rocket-propelled grenade round
Service note
Late Cold War RPG-7 ammunition variant still encountered in 21st-century conflicts
Designer
Bazalt
Designed
1977
Produced
Introduced in the late Cold War; later produced or listed by multiple RPG-7 ammunition producers

Specifications

Launcher compatibility
RPG-7V/RPG-7V1-family 40 mm launchers
Round designation
PG-7VL round with PG-7L anti-tank grenade
Warhead type
Single-stage HEAT
Launcher caliber
40 mm
Warhead caliber
93 mm
Round weight
2.59 kg to 2.6 kg
Grenade weight
2.2 kg in VMZ Sopot data
Propellant charge weight
0.39 kg in VMZ Sopot data
Muzzle velocity
112 m/s
Direct fire range
250 m
Sighting or effective range
300 m
Armor penetration
500 mm homogeneous armor / RHA class
Construction penetration
1.7 m brick, 1.2 m reinforced concrete, or 2.4 m log-and-soil in Rosoboronexport data
Packaging
Six rounds per case; 880 x 500 x 295 mm case dimensions and 38 kg gross weight in VMZ Sopot data
Round Identity

The PG-7VL is the complete RPG-7-compatible round, while PG-7L is the anti-tank grenade section named in VMZ Sopot's product listing. Stronger product sources support a 300 m sighting or effective range for this round; the page therefore avoids broader launcher-family range figures that belong to other RPG-7 ammunition.

Designation

PG-7VL round with PG-7L anti-tank grenade.

Warhead class

Single-stage HEAT round with a 93 mm warhead.

Documented conflict evidence

Open-source conflict records show seized or held PG-7VL projectiles, not a named firing incident.

Variants

PG-7-series naming distinguishes the complete rocket-propelled grenade round from the grenade or warhead section, while adjacent PG-7 records cover other single-charge and tandem RPG-7 ammunition.

VariantConfigurationDesignation notes
PG-7LAnti-tank grenade section

VMZ Sopot identifies the product as a PG-7VL round with PG-7L anti-tank grenade, making PG-7L the grenade section named inside the complete round designation.

Sources: PG-7VL round with PG-7L anti-tank grenade

PG-7VM rocket-propelled grenade, RPG-7 HEAT rocket-propelled grenade round, MunitionsPG-7VM rocket-propelled grenadeEarlier lighter single-charge HEAT round

Rosoboronexport lists PG-7VM and PG-7VL together among RPG-7V1-compatible HEAT rounds; VMZ Sopot's product pages place both in its RPG-7V ammunition line.

Sources: RPG-7V1, PG-7VL round with PG-7L anti-tank grenade

PG-7VR tandem-charge RPG projectile, Tandem-charge RPG projectile, Infantry WeaponsPG-7VR tandem-charge RPG projectileLater tandem-charge HEAT family member

Rosoboronexport lists PG-7VR in the same RPG-7V1 HEAT ammunition family, but the linked catalog page covers the later tandem-charge projectile rather than the single-charge PG-7VL.

Sources: RPG-7V1

Launch Platforms

Public sources place the PG-7VL in the RPG-7 launcher-family ammunition set.

LauncherLauncher typeLaunch evidence
RPG-7, Reusable shoulder-fired anti-tank rocket launcher, Infantry WeaponsRPG-7RPG-7V-series launcher

Rosoboronexport lists PG-7VL among rounds fired by the RPG-7V1 launcher, while Modern Firearms places PG-7VL in the RPG-7 ammunition family.

Sources: RPG-7V1, RPG-7 grenade launcher

Timeline

PG-7VL rocket-propelled grenade Key Events

  1. PG-7VL enters the RPG-7 ammunition family

    Modern Firearms and GunRF place the PG-7VL/Luch round in the 1977 generation of RPG-7 ammunition, with a heavier 93 mm HEAT warhead than earlier PG-7V and PG-7VM rounds.

    Sources: RPG-7 grenade launcher, GunRF PG-7VL round

  2. PG-7VL recovered from Islamic State cell in Deir ez-Zor

    Militant Wire identified a PG-7VL rocket among weapons seized by SDF forces from Islamic State in Al-Shahel, Deir ez-Zor.

    Sources: Weaponry of the Islamic State in AANES

  3. PKK weapons review identifies Bulgarian PG-7VL projectile

    Militant Wire's 2021 PKK weapons review identified a Bulgarian PG-7VL projectile in the hands of a PKK fighter and described RPG-7 launchers and projectile variants in PKK use and seizures.

    Sources: Weapons Used and Captured by the PKK in 2021

Media

PG-7VL rocket-propelled grenade Images

Related Weapon Systems
PG-7VM rocket-propelled grenade, RPG-7 HEAT rocket-propelled grenade round, MunitionsMunitionsPG-7VM rocket-propelled grenadeRPG-7 HEAT rocket-propelled grenade roundThe PG-7VM is an RPG-7-compatible high-explosive anti-tank round built around the smaller PG-7M-class shaped-charge grenade. VMZ Sopot and STV Group publish closely aligned data for a roughly 1.97 kg round with a 300 m direct-fire range, 500 m sighting range, and about 300 mm armor penetration; conflict evidence documents the round in PKK, Islamic State, and Iraqi insurgent stocks, usually as seized or photographed ammunition rather than a named firing incident.
RPG-7, Reusable shoulder-fired anti-tank rocket launcher, Infantry WeaponsInfantry WeaponsRPG-7Reusable shoulder-fired anti-tank rocket launcherThe RPG-7 is a Soviet-origin reusable shoulder-fired rocket launcher built around a simple 40 mm launch tube and a wide family of over-caliber anti-armor, fragmentation, and thermobaric rounds. Its low cost, portability, and large global stock make it a common infantry anti-armor and assault weapon, including documented Ukrainian service, Hamas use in Gaza, ISWAP use in the 2009 Boko Haram Insurgency, and insurgent use in Afghanistan.
Drone-dropped modified RPG or shaped-charge munition, Improvised drone-dropped RPG-derived shaped-charge munition, MunitionsMunitionsDrone-dropped modified RPG or shaped-charge munitionImprovised drone-dropped RPG-derived shaped-charge munitionDrone-dropped modified RPG or shaped-charge munitions are field-adapted explosive payloads that convert RPG-family projectiles or similar shaped-charge warheads into aerial drop weapons for commercial UAVs. Open-source conflict reporting documents PKK Matrice 600-family carriage of PG-7VM, PG-7VL, and OG-7-pattern projectiles in 2021 and Hamas-led use of modified RPG-derived munitions from commercial drones during the 7 October 2023 attack on Israel.
