FZ231 rocket launcher

Also known as
  • FZ 231
  • FZ231 (12-tube)
  • FZ231 rocket pod
  • FZ231 70 mm launcher
  • FZ231 2.75-inch launcher
  • FZ231 12-tube rocket pod

The FZ231 is Thales Belgium's reusable 12-tube composite 70 mm rocket launcher for helicopters, with a Launcher Interface Unit distinguishing it from the closely related FZ219. It fires FZ 2.75-inch FFAR and WA rocket motors and is documented on AW109, H145M, and HAL LCH/Prachand aircraft, while public documentation identifies platform integration and firing tests rather than independent battlefield employment of the launcher itself.

FZ231 rocket launcher, Composite 70 mm rocket launcher, Munitions
Image source: FZ231 product image
Profile / Specs

Profile

Origin
Belgium
Type
Composite 70 mm rocket launcher
Designed
1998 composite FZ225/FZ231/FZ233 launcher portfolio

Specifications

Tube count
12
Launcher class
Lightweight composite reusable rocket launcher
Height
361 mm
Width
324 mm
Overall length
1658 mm
Total mass (empty)
31 kg
Firing mode
Ripple / single
Intervallometry
80 ms minimum
Compatible rocket motors
FZ 2.75-inch FFAR and WA rocket motors
Interface
Launcher Interface Unit (LIU)
Optional fit
Removable rear fairing
Variants

Thales Belgium's composite helicopter-launcher family separates tube count and interface fit; the FZ231 is the 12-tube launcher fitted with a Launcher Interface Unit.

VariantConfigurationDesignation notes
FZ21912-tube launcher without LIU

Thales describes the FZ219 as the same 12-tube composite helicopter-launcher design as the FZ231, but without the Launcher Interface Unit.

Sources: FZ219 official product page, FZ231 official product page

FZ2337-tube lightweight composite launcher

Thales lists the FZ233 as the 7-tube alternative to the FZ231 in H145M rocket-system fits.

Sources: Thales H145M compatibility page

FZ22519-tube lightweight composite launcher

Thales history groups FZ225, FZ231, and FZ233 as a composite launcher portfolio developed and produced for lightweight helicopter carriage.

Sources: Thales Belgium history

Carrier Aircraft

Thales Belgium documents the FZ231 as a helicopter-mounted 12-tube 70 mm rocket launcher, with an existing catalog link for the AW109 family.

CarrierCarrier typeCarriage evidence
AW-109, Light twin-engine attack and utility helicopter, Aircraft & UAVsAW-109Light utility helicopter

Thales Belgium's A109 LUH compatibility page shows AW109-family variants fitted with as many as two FZ231 12-tube lightweight composite launchers.

Sources: A109 LUH compatibility page

Compatible Rockets

The FZ231 is part of Thales Belgium's 2.75-inch / 70 mm FZ rocket system and uses the same launcher ecosystem as related FZ rockets.

Launched itemItem typeLaunch evidence
2.75-inch rockets, Unguided 2.75-inch air-launched rocket family, Munitions2.75-inch rockets70 mm rocket family

The FZ231 product page states that the launcher fires FZ 2.75-inch FFAR and WA rocket motors with conventional or remote-set-fuze warheads.

Sources: FZ231 official product page

FZ90 rocket motor, 70 mm wrap-around rocket motor, MunitionsFZ90 rocket motorWA rocket motor

Thales' AW109, H145M, and LCH compatibility pages list FZ90 rocket motors among the rockets carried with FZ231 launcher fits.

Sources: A109 LUH compatibility page, Thales H145M compatibility page, Thales LCH compatibility page

FZ275 LGR, Laser-guided 70 mm rocket, MunitionsFZ275 LGRLaser-guided 70 mm rocket

Thales describes FZ275 LGR as fireable from standard FZ rocket launchers, while dedicated smart launchers add full bidirectional and lock-on-before-launch functions.

Sources: FZ275 official product page

Guided-rocket limit

The FZ231 page supports standard FZ rocket firing; Thales separately identifies FZ606 and FZ800 smart launchers for full FZ275 LGR functionality.

Sources: FZ231 official product page, FZ275 official product page

Launcher Compatibility

Manufacturer and platform documentation describe FZ231 as a helicopter launcher rather than a standalone battlefield weapon. The fits below are platform-integration context; they do not by themselves establish FZ231 direct conflict use.

PlatformFZ231 fitSourced context
AW-109, Light twin-engine attack and utility helicopter, Aircraft & UAVsAW109 familyUp to two 12-tube launchersThales lists A109 LUH/LOH variants fitted with FZ231 launchers and FZ90 rockets, with growth potential for FZ275 LGR.
Airbus H145M / EC645 T2Up to two 12-tube launchers, or FZ233 7-tube alternativesAirbus reported H145M HForce development firing in Hungary with Thales FZ231 among the tested weapons; Thales lists the same platform with FZ231 and FZ233 options.
HAL Light Combat Helicopter / PrachandUp to four 12-tube launchersThales lists the HAL LCH with four stub-wing FZ231 launchers, and Defense News later described Prachand stub wings carrying as many as four FZ231 70 mm rocket pods.

Sources: FZ231 official product page; A109 LUH compatibility page; Thales H145M compatibility page; Thales LCH compatibility page; Airbus H145M HForce firing campaign; Defense News Prachand tender report.

Timeline

FZ231 rocket launcher Key Events

  1. FZ enters 70 mm rocket production

    Forges de Zeebrugge began manufacturing complete 2.75-inch / 70 mm rockets under a U.S. Navy license, establishing the rocket family that later launchers such as FZ231 support.

  2. Composite launcher family developed

    Thales Belgium's history identifies development and production of the FZ225, FZ231, and FZ233 composite launcher portfolio for lighter helicopter payloads and improved endurance.

  3. H145M HForce firing campaign

    Airbus reported H145M HForce ballistic testing in Hungary with Thales FZ231 listed for the unguided-rocket element, and Thales separately lists H145M compatibility with two FZ231 launchers.

  4. Prachand tender context

    Defense News reported India's large Prachand light-attack helicopter tender with stub wings described as carrying up to four FZ231 70 mm rocket pods.

Media

FZ231 rocket launcher Images

FZ231 rocket launcher, Composite 70 mm rocket launcher, Munitions - view 1
Source: FZ231 official product page
