60 mm M62 practice shell

Also known as

60mm M62 practice shell
60mm M62 mortar bomb practice
60MM PRACTICE MORTAR SHELL M62
M62 practice mortar shell
60 mm M62 practice mortar shell
M62 practice shell
Yugoimport 60 mm M62 practice shell

The 60 mm M62 practice shell is a Yugoslav-pattern training mortar round sold by Yugoimport-SDPR for short-range practice firing. Yugoimport lists the complete shell at 1,080 g and publishes the same 50-280 m ballistic envelope for use with the 60 mm Mortar M57 and 60 mm Commando Mortar M70, while propellant and reseller references independently preserve the M62 practice-shell designation.

60 mm M62 practice shell, 60 mm practice mortar shell, Munitions

Image source: 60mm-Mortar-Rounds.jpg

Profile / Specs

Profile

Origin: Yugoslavia / Serbia
Built by: Yugoimport SDPR
Built in: Serbia
Type: 60 mm practice mortar shell
Service note: Modern Serbian export ammunition

Specifications

Caliber: 60 mm
Projectile length: 193 mm
Shell length: 202 mm
Projectile mass: 235 g
Shell mass: 1080 g
Compatible mortar setup: 60 mm Mortar M57 with 720 mm barrel; Commando M70 with 650 mm barrel
Ballistic data: Maximum range 280 m; minimum range 50 m when used with the listed M57 or Commando M70 mortar setup.
Propellant application: Milan Blagojevic - Namenska lists NGB-051 flake propellant for 60 mm mortar shells, including M62 practice shells.
Packing: 1 complete shell per carton; 12 cartons per wooden box
Wooden box: 52 x 33 x 19 cm; total mass 18 kg; total volume 0.033 cubic meters

Firing Weapon

Yugoimport identifies this practice shell as ballistically configured for specific 60 mm mortars.

Firing weapon

Weapon type

Firing evidence

60 mm M57 mortar, 60 mm light infantry mortar, Artillery

60 mm M57 mortar

60 mm light infantry mortar

Yugoimport states that the 60 mm M62 practice shell is ballistically configured for use with the 60 mm Mortar M57.

Sources: 60 mm, M62 - Yugoimport

Compatible Mortars

Yugoimport publishes ballistic data for the 60 mm M62 practice shell with two short 60 mm mortar setups. The public record supports compatibility and training use, but it does not independently document battlefield use of this exact practice shell.

Mortar	Barrel length	Published ballistic data
60 mm M57 mortar	720 mm	Maximum range 280 m; minimum range 50 m.
60 mm Commando Mortar M70	650 mm	Maximum range 280 m; minimum range 50 m.

Training role

The round is cataloged as a practice mortar shell, with a complete shell mass of 1,080 g and a 235 g projectile.

Propellant context

Milan Blagojevic - Namenska lists NGB-051 flake propellant for 60 mm mortar shells, including M62 practice shells.

Packaging

Yugoimport lists one complete shell per carton and 12 cartons per wooden box.

Media

60 mm M62 practice shell Images

60 mm M62 practice shell, 60 mm practice mortar shell, Munitions - view 1 — Source: M69 Practice Round, used as practice 60 mm mortar round - Fort Devens Museum - DSC07147.JPG

Related Weapon Systems

60 mm M08 illuminating shell, 60 mm illuminating mortar shell, Munitions

Munitions60 mm M08 illuminating shell60 mm illuminating mortar shellThe 60 mm M08 illuminating shell is a Serbian/Yugoimport 60 mm mortar illumination round for the M57 light mortar. Yugoimport's sheet describes a TP M67 time-fuzed, parachute-retarded candle round with 180,000 cd output for 35 seconds, a 2.5 m/s descent rate, and a 400-2,450 m firing envelope from the 720 mm-barrel M57.

Artillery60 mm Commando Mortar M7060 mm commando mortarThe 60 mm Commando Mortar M70 is a compact 60 mm infantry mortar in the former Yugoslav mortar family. UnisGroup and Armatec list the M70 as a two-person commando mortar with a 650 mm barrel, 94-1,630 m high-explosive range band, and 20-25 round-per-minute firing rate, while Yugoimport ballistic data ties the same Commando M70 barrel length to the 60 mm M62 practice shell.

60 mm M73 HE mortar shell, 60 mm high-explosive mortar shell, Munitions

Munitions60 mm M73 HE mortar shell60 mm high-explosive mortar shellThe 60 mm M73 HE mortar shell is a Serbian high-explosive round in the Yugoimport and Krušik 60 mm mortar-shell catalogs. Beyond catalog data for M57 mortar firing, open reporting and UN monitoring have tied M73 rounds to Ukrainian use, al-Shabaab mortar attacks in Somalia, and seized ammunition after the 2023 Banjska attack.

120 mm HE M62P8 mortar shell, 120 mm high-explosive mortar shell, Munitions

Munitions120 mm HE M62P8 mortar shell120 mm high-explosive mortar shellThe 120 mm HE M62P8 is a Yugoslav-origin high-explosive mortar shell for 120 mm mortars, documented by Yugoimport with 606 mm overall length, 12.6 kg mass, TNT fill, and a UTU/M93P1 superquick-delay fuze. In Libya, a UN Panel of Experts report listed Krušik 120 mm M62P8 mortar bombs as an ammunition-transfer violation for Hafter-affiliated forces during the 2014 Second Libyan Civil War.

60 mm Mk10 smoke shell, 60 mm smoke mortar shell, Munitions

Munitions60 mm Mk10 smoke shell60 mm smoke mortar shellThe 60 mm Mk10 smoke shell is a Serbian smoke mortar round in the Krušik and Yugoimport 60 mm mortar-ammunition catalogs. Official sheets identify a 410 mm, 2.1 kg fuzed shell with a UT M88P1 impact fuze, ignition cartridge, increment charges, and M57 mortar ballistic data; the Krušik product image specifies a white-phosphorus smoke charge and a 5.035 km maximum range from a 1200 mm barrel.

120 mm HAL-20 mortar shell with fuze UT M88 P2, 120 mm thermobaric mortar shell, Munitions

Munitions120 mm HAL-20 mortar shell with fuze UT M88 P2120 mm thermobaric mortar shellThe 120 mm HAL-20 mortar shell with fuze UT M88 P2 is a Serbian thermobaric mortar round in Yugoimport's 120 mm ammunition line. Yugoimport's brochures describe it as a UT M88 P2-fuzed shell with M74 ignition, six increment charges, thermobaric PBX fill, and ballistic data for the 120 mm M75 mortar.

60 mm M57 mortar, 60 mm light infantry mortar, Artillery

Artillery60 mm M57 mortar60 mm light infantry mortarThe 60 mm M57 is a Yugoslav-pattern smoothbore light infantry mortar now listed by Serbian manufacturer PPT Namenska and in Yugoimport export material. Its official sheets describe a high-angle fire-support weapon built around barrel, base plate, bipod, sight, tools, spares, and accessories; post-Yugoslav records also show Serbian surplus stocks and Balkan export activity. In the 2020 Nagorno-Karabakh Conflict, open-source loss documentation recorded M57 mortars captured from Armenian forces.

60 mm mortar, Light infantry mortar, Artillery

Artillery60 mm mortarLight infantry mortarThe 60 mm mortar is a portable light-infantry indirect-fire class used for close support where crews need high-angle fire from a weapon lighter than larger battalion mortars. The caliber family spans many national models: direct conflict sourcing documents PKK 60 mm mortar use and recovered ammunition in the Kurdish-Turkish conflict, disputed Thai 60 mm mortar fire claims in the 2025 Thailand-Cambodia border fighting, and Yemen-linked interdiction of 60 mm mortar tubes assessed by the United States as intended for Houthi forces rather than confirmed battlefield firing.

Sources

60 mm, M62 - YugoimportPublisher: Yugoimport-SDPR | Note: Supports manufacturer background and specifications for the 60 mm M62 practice shell, including dimensions, mass, packing, and ballistic data with the 60 mm Mortar M57 and Commando M70. | Accessed: 2026-07-04 60 mm Mortar M70 - ArmatecPublisher: Armatec | Note: Supports background context for the 60 mm Commando Mortar M70, including its 650 mm barrel length, 60 mm caliber range, weight class, and mortar role. | Accessed: 2026-07-04 Celluloid containers and powders for mortar shells - Milan Blagojevic - NamenskaPublisher: Milan Blagojevic - Namenska | Note: Supports propellant and application context by listing NGB-051 flake propellant for 60 mm mortar shells, including M62 practice shells. | Accessed: 2026-07-04 60MM PRACTICE MORTAR SHELL M62 - Mil-Spec IndustriesPublisher: Mil-Spec Industries | Note: Supports exact-name background context for the 60 mm practice mortar shell M62 as 60 mm practice mortar ammunition; not used for image rights. | Accessed: 2026-07-04 60mm-Mortar-Rounds.jpgPublisher: Wikimedia Commons | Note: Supports image provenance for the primary gallery image: an openly licensed comparison photo showing 60 mm mortar rounds, including an M69 training/practice round. | Accessed: 2026-07-04 M69 Practice Round, used as practice 60 mm mortar round - Fort Devens Museum - DSC07147.JPGPublisher: Wikimedia Commons | Note: Supports image provenance for an additional CC0 museum photograph used as a close visual reference for 60 mm practice mortar ammunition. | Accessed: 2026-07-04
