152 mm round for Giatsint howitzer

Also known as
  • TRM 152 mm round for Giatsint
  • 152 mm round for 2A36 Giatsint-B and 2A37 Giatsint-S
  • OF-45

Transmobile's 152 mm round for Giatsint howitzer is a Bulgarian-listed Frag-HE artillery round for the 2A36 Giatsint-B and 2A37 Giatsint-S guns. Its product data gives a 43.56 kg OF-45 projectile, 864 m/s muzzle velocity, 6,500 to 24,700 m range, and an RGM-2 PD fuze; separate 3OF29 references are kept as Giatsint-family context, not as proof that the Transmobile round carries that designation.

152 mm round for Giatsint howitzer, 152 mm Frag-HE artillery round, Munitions
Image source: Wikimedia Commons 152 mm 3OF29 high explosive round
Profile / Specs

Profile

Origin
Bulgaria
Type
152 mm Frag-HE artillery round
Service note
Commercial Bulgarian Giatsint-family ammunition
Produced
Current commercial production

Specifications

Caliber
152 mm
Round type
HE-frag artillery projectile
Compatible weapons
Transmobile lists 2A36 Giatsint-B and 2A37 Giatsint-S; the catalog links 2A37 context through the 2S5 Giatsint-S platform
Projectile designation in Transmobile row
OF-45
Minimum fire range
6,500 m
Maximum fire range
24,700 m
Muzzle velocity
864 m/s
Projectile weight
43.56 kg
Fuze type
RGM-2 PD
RGM-2 fuze action
Mechanical nose point-detonating fuze with selectable super-quick or delayed action
3OF29 reference context
Separate Soviet/Russian steel-bodied, boat-tailed HE-frag projectile documented for Giatsint systems
Direct fire range
1,000 m
Firing Weapons

Open-source references identify Giatsint-family 152 mm high-explosive rounds for the towed 2A36 gun and the 2A37 gun mounted on the 2S5 platform.

Firing weaponWeapon typeFiring evidence
2A36 Giatsint-B, 152 mm towed field gun, Artillery2A36 Giatsint-B152 mm towed field gun

Transmobile lists the Bulgarian TRM round for use with the 2A36 Giatsint-B gun.

Sources: Transmobile 152 mm round for Giatsint howitzer

2S5 Giatsint-S, 152 mm tracked self-propelled gun, Artillery2S5 Giatsint-S152 mm tracked self-propelled gun

Transmobile lists compatibility with the 2A37 Giatsint-S gun, while Tank-AFV and Commons identify 3OF29 as a separate Giatsint-family HE-frag round tied to the 2S5 platform.

Sources: Transmobile 152 mm round for Giatsint howitzer, Tank-AFV 2S5 Giatsint-S, Wikimedia Commons 152 mm 3OF29 high explosive round

Design Notes

The Transmobile listing and the 3OF29 references describe closely related Giatsint-family ammunition, but they should not be merged into one designation without a direct source. Transmobile's product row names OF-45 in the projectile-weight field, while the Commons image and Fenix Insight page identify a separate 3OF29 reference projectile for the same gun family.

Transmobile product

Frag-HE 152 mm round for 2A36 Giatsint-B and 2A37 Giatsint-S with 43.56 kg listed projectile weight, 864 m/s muzzle velocity, and RGM-2 PD fuze.

Source: Transmobile 152 mm round for Giatsint howitzer.

3OF29 context

Fenix Insight and Commons identify 3OF29 as a Soviet/Russian HE-frag projectile for Giatsint systems, useful for compatibility context but not as proof of the Transmobile product designation.

Sources: Fenix Insight 3OF29; Wikimedia Commons 152 mm 3OF29 high explosive round.

Fuze context

Arcus describes RGM-2 as a mechanical nose point-detonating fuze for 122 mm, 130 mm, and 152 mm howitzer ammunition with super-quick or delayed action settings.

Source: Arcus RGM-2 fuze.

Timeline

152 mm round for Giatsint howitzer Key Events

  1. Photographed at Russia Expo Arms

    Wikimedia Commons records a 3OF29 reference round photographed at Russia Expo Arms 2013, captioning it as ammunition for the 2A36 and 2S5 artillery systems.

    Sources: Wikimedia Commons 152 mm 3OF29 high explosive round

  2. Transmobile page updated

    Transmobile's product page was last updated on 20 February 2021, listing a Bulgarian TRM Frag-HE round with range, velocity, OF-45 projectile-weight, and fuze data for the Giatsint family.

    Sources: Transmobile 152 mm round for Giatsint howitzer

Related Weapon Systems
2S5 Giatsint-S, 152 mm tracked self-propelled gun, ArtilleryArtillery2S5 Giatsint-S152 mm tracked self-propelled gunThe 2S5 Giatsint-S is a Soviet 152 mm tracked self-propelled gun built for long-range corps- and army-level fire support. Its open rear-mounted 2A37 gun gives it greater reach than many older Soviet 152 mm systems, while its tracked chassis and stabilizing rear spade support shoot-and-move artillery work. Sources document 2S5 use or fielding context from Afghanistan and Chechnya through the 2014 Russia-Ukraine War, with additional wartime transfer evidence for Ethiopia during the Eritrean-Ethiopian War.
122 mm artillery round, 122 mm artillery ammunition, MunitionsMunitions122 mm artillery round122 mm artillery ammunitionThe 122 mm artillery round is a family-level label for Soviet-origin medium-caliber artillery ammunition used by D-30-type towed howitzers and 2S1 Gvozdika self-propelled howitzers. Manufacturer and military references describe separate-loading HE projectiles with full or reduced propelling charges, while U.S. security-assistance reporting documents 122 mm artillery rounds among ammunition committed to Ukraine and TWZ reporting describes a pair of 122 mm rounds as a standard AQ-400 Scythe payload.
152 mm D-1 gun-howitzer, Towed 152 mm howitzer, ArtilleryArtillery152 mm D-1 gun-howitzerTowed 152 mm howitzerThe 152 mm D-1 gun-howitzer is a Soviet towed heavy howitzer that put a short 152.4 mm ordnance on a lighter split-trail carriage. Its modern record is mostly residual-use evidence: Russia drew D-1 guns from stocks during the full-scale phase of the 2014 Russia-Ukraine War, while open loss records tie the same World War II-era system to Armenian/Artsakh equipment in 2020 Nagorno-Karabakh and Syrian government artillery losses in the 2011 Syrian Civil War.
3OF56 122 mm HE-Frag Projectile, 122 mm high-explosive fragmentation projectile, MunitionsMunitions3OF56 122 mm HE-Frag Projectile122 mm high-explosive fragmentation projectile3OF56 is a Soviet-era 122 mm high-explosive fragmentation artillery projectile for D-30/2A18-family guns and the 2A31 gun of the 2S1 Gvozdika. Public references do not describe the designation consistently: Fenix Insight identifies it as a nose-fuzed, boat-tailed, spin-stabilised HE-frag projectile, while U.S. WEG/FAS tables place a 3OF-56 complete projectile weight in a rocket-assisted ammunition row for the D-30A and 2S1.
155 mm NATO ammunition, 155 mm NATO-standard artillery ammunition family for 39-, 45-, and 52-caliber howitzers, MunitionsMunitions155 mm NATO ammunition155 mm NATO-standard artillery ammunition family for 39-, 45-, and 52-caliber howitzers155 mm NATO ammunition is a family of separately loaded artillery projectiles, fuzes, primers, and propelling charges built around NATO and JBMoU interoperability standards rather than a single shell. Official records document 155 mm artillery rounds in Ukraine's wartime ammunition supply and in coalition M777A2 fire missions against ISIS, while manufacturer lines show high-explosive, extended-range, training, modular-charge, and specialty projectile examples.
