Deep-water multibeam sounding system

Also known as
  • 深水多波束测深系统
  • 全海深多波束测深系统
  • deep-water multibeam echosounder
  • deep-water multibeam sonar system
  • full-ocean-depth multibeam sounding system
  • full-ocean-depth multibeam echosounder

Deep-water multibeam sounding system is a Chinese full-ocean-depth hydrographic survey sonar class for seabed mapping from shallow water to 11,000 m. Chinese official reporting credits the program to a Chinese Academy of Sciences Institute of Acoustics-led effort, with early trials on Shiyan 3 and a later Haixun 08 GONDOLA installation for full-ocean-area surveying.

Deep-water multibeam sounding system, Hydrographic survey system, Support Equipment
Image source: China Society: Haixun 08 survey equipment
Profile / Specs

Profile

Origin
China
Type
Hydrographic survey system
Service note
Prototype accepted in 2014; engineering application project accepted in 2018; Haixun 08 shipboard fit documented in 2024.
Designed
c. 2008-2018
Produced
Prototype accepted in 2014; engineering prototype accepted in 2018.

Specifications

Operating depth envelope
20-11,000 m
Documented Haixun 08 depth
Up to 10,000 m
Prototype acceptance depth
11,000 m
Typical operating frequency
About 12 kHz
Array layout
Separate hull-mounted transmit and receive arrays
Demonstration survey lines
More than 6,000 km in the South China Sea, northwest Pacific, and Indian Ocean
Initial test platform
Shiyan 3 research vessel
Mounting
GONDOLA hull structure
Survey role
Full-ocean-area bathymetric surveying
Companion systems
Medium-water and shallow-water multibeam sounding systems
Carrier Vessel

Haixun 08 carries the system in a GONDOLA structure for full-ocean-area surveying.

CarrierCarrier typeCarriage evidence
Haixun 08, Hydrographic survey and patrol ship, Naval SystemsHaixun 08Hydrographic survey vessel

The China Society article says Haixun 08 uses a GONDOLA structure to carry a deep-water multibeam sounding system for full-ocean-area surveying.

Sources: China Society: Haixun 08 survey equipment

Documented vessel connection

The source documents the sensor as part of Haixun 08's survey suite; no direct source ties the sensor itself to separate conflict use.

Sources: China Society: Haixun 08 survey equipment

Survey-System Context

The system is a shipboard hydrographic sensor, so its strongest public context is the Chinese full-ocean-depth program's move from prototype trials to documented shipboard survey fits.

ContextSourced detail
Prototype phaseOfficial reporting says the system reached an 11,000 m maximum detection depth and was tested aboard Shiyan 3.
Engineering phaseThe later application-demonstration project covered 20-11,000 m mapping and more than 6,000 km of survey lines in multiple ocean areas.
Haixun 08 fitHaixun 08 is documented carrying a 10,000 m-capable deep-water multibeam system in a GONDOLA structure with medium- and shallow-water companion systems.
Timeline

Deep-water multibeam sounding system Key Events

  1. Domestic prototype accepted

    China's Ministry of Science and Technology said the deep-water multibeam project passed acceptance after producing a domestic prototype with a maximum 11,000 m detection depth.

    Sources: MOST: Deep-water multibeam system acceptance

  2. Engineering application project accepted

    The China 21st Century Agenda Management Center reported acceptance of the full-ocean-depth engineering and application-demonstration project led by the CAS Institute of Acoustics.

    Sources: ACCA21: Full-ocean-depth multibeam acceptance

  3. Institute explainer details sensor layout

    The CAS Institute of Acoustics published a technical explainer describing hull-mounted transmit and receive arrays, the roughly 12 kHz operating frequency, and real-time beam-stabilization needs.

    Sources: IOA CAS: Measuring 11,000 m water depth

  4. Haixun 08 shipboard fit documented

    The China Society article described Haixun 08 carrying a 10,000 m-capable deep-water multibeam system in a GONDOLA structure alongside medium- and shallow-water multibeam systems.

    Sources: China Society: Haixun 08 survey equipment
