ADM 401

Also known as

84 mm ADM 401
Carl-Gustaf ADM 401
Carl Gustaf ADM 401
Saab ADM 401

ADM 401 is Saab's 84 mm Carl-Gustaf area-defence munition for close-in protection. It is cataloged as relationship-only ammunition tied to the Carl-Gustaf launcher family because the specific flechette round is documented by role, payload, and compatibility rather than by independent conflict use.

ADM 401, 84 mm area defence munition, Munitions

Image source: Saab ADM 401 image asset

Profile / Specs

Profile

Origin: Sweden
Built by: Saab
Type: 84 mm area defence munition

Specifications

Caliber: 84 mm
Payload: About 1,100 flechettes
Effective range: About 100 m
Weight: 2.7 kg
Warhead design: Flechette cluster
Release method: Gas pressure
Target effect: Enemy troops in the open and soft-skinned vehicles
System compatibility: Carl-Gustaf 84 mm weapon family
Family compatibility: Saab says every 84 mm Carl-Gustaf munition is compatible with every version of the weapon

Firing Weapon

Saab places ADM 401 in the Carl-Gustaf 84 mm ammunition family for close-in protection, and its M4 product page describes all 84 mm Carl-Gustaf munitions as compatible across weapon versions.

Carrier

Carrier type

Carriage evidence

Carl Gustaf recoilless rifle, Recoilless rifle, Infantry Weapons

Carl Gustaf recoilless rifle

84 mm recoilless rifle

Saab says ADM 401 is a Carl-Gustaf round that carries about 1,100 flechettes for close-in protection, while the Carl-Gustaf M4 product page describes the wider 84 mm ammunition family as compatible with every weapon version.

Sources: Saab ADM 401 fact sheet, Saab Carl-Gustaf M4 product page

Effect And Compatibility

ADM 401 is best read as a close-protection round inside the Carl-Gustaf ammunition family: Saab identifies the launcher family, payload, intended target set, and short effective range, but does not present it as a separate conflict-attributed weapon.

Feature	Sourced detail	Reader note
Payload	About 1,100 flechettes.	The round is an anti-personnel area-defence munition rather than a shaped-charge anti-armour round.
Release method	Gas pressure releases the flechette payload instead of an explosive charge.	This distinguishes the effect mechanism from high-explosive Carl-Gustaf ammunition.
Intended targets	Troops in the open and soft-skinned vehicles at about 100 m.	The short range places the round in close-in protection use.
Firing weapon	Carl Gustaf recoilless rifle 84 mm family.	Saab describes all 84 mm Carl-Gustaf munitions as compatible with every version of the weapon.
